Parts Breakdown
Model BE-IT-0015M
Item No. Description
AM387 Screw TE M8x12 Zinc for 47582
AM388 Plate 15 Div. for 47582
AM389 Head 15 Div. for 47582
Model BE-IT-0030M
Item No. Description
AM395 Head 30 Div. for 47583
AM396 Plate 30 Div. for 47583
AM387 Screw TE M8x12 Zinc for 47583
47582
Position Item No. Description
1 AM390 Support for 47582
2 AM391 Screw TCEI M12x50 Zinc. for 47582
3 AM392 Head Ring D.400 for 47582
47583
Position Item No. Description
1 AM390 Support for 47583
2 AM391 Screw TCEI M12x50 Zinc for 47583
3 AM397 Knife 30 Div for 47583
15 Div. Knife Group
Position Item No.
4 AM393
5 AM394
6
30 Div. Knife Group
Position Item No.
4 AM392
5 AM398
6
30
Description Position
Knife 15 Div. for 47582 7
15 Div. Knife Group for 47582
Description Position
Head Ring D.400 for 47583 7
30 Div. Knife Group for 47583
