Omcan BE-IT-0015M Instruction Manual page 28

Parts Breakdown
Model BE-IT-0015M
Model BE-IT-0030M
Item No.
AM447
AM448
Item No. Description
AM280 Pin for 47582, 47583
AM281 Seal OR 6200 for 47582, 47583
Screw TSPEI M6x12 Zinc for 47582,
AM282
47583
AM283 Ring for 47582, 47583
Item No. Description
AM315 Sliding Trolley for 47582, 47583
AM316 Shoe Guide for 47582, 47583
Sliding Sleeve with Spheres for 47582,
AM317
47583
Item No. Description
Motor kW 0.55 6 Poli B3 220/380/60 UL/
AM322
CSA Three Phases for 47582, 47583
AM323 Screw TE M8x25 Zinc for 47582, 47583
AM324 Motor Pin for 47582, 47583
AM325 Seeger Ring D.18 for 47582, 47583
47582
47583
Description Position
Front Protection for 47582, 47583 1
Rear Protection for 47582, 47583 2
Position Item No. Description
1 AM220 Washer D.8 Inox for 47582, 47583
2 AM284 Stopper for 47582, 47583
3 AM285 Screw TE M8x45 Inox for 47582, 47583
4 AM286 Screw TE M8x20 Inox for 47582, 47583
Position Item No. Description
1 AM197 Washer D.6 Zinc for 47582, 47583
2 AM318 Screw TCEI M6x16 Zinc for 47582, 47583
3 AM319 Pin Holder for 47582, 47583
Position Item No. Description
1 AM326 Motor Fixing Shelf for 47582, 47583
Threaded Bar M8x85 Zinc for 47582,
2 AM327
47583
3 AM328 Nut M8 Zinc for 47582, 47583
4 AM239 Nut M8 Zinc for 47582, 47583
Knife Safety Group
Item No. Description
Screw TCBEI M6x12 Inox for 47582,
AM449
47583
AM450 Knife Safety Group for 47582, 47583
Rounding Plate Group
Position Item No.
5 AM287
6 AM288
7 AM289
8
Sliding Trolley Group
Position Item No.
4 AM320
5 AM321
6
Position Item No.
5 AM299
6 AM329
7
8
28
Position
3
Description Position
Stopper for 47582, 47583 9
Rounding Plate for 47582, 47583 10
Rounding Plate Group for 47582, 47583
Description Position
Screw STEI M8x35 for 47582, 47583 7
Sliding Trolley Group for 47582, 47583
Motor Group
Description Position
Washer D.8x24 SP. 4 for 47582, 47583 9
Motor Group for 47582, 47583
