Omcan BE-IT-0015M Instruction Manual page 29

Model BE-IT-0015M
Model BE-IT-0030M
Item No.
AM451
AM211
Item No. Description
AM453 Key 6x6x18mm for 47582, 47583
AM454 Fork for 47582, 47583
AM455 Plug D.30 for 47582, 47583
AM456 Lever for 47582, 47583
AM211 Screw STEI M6x10 for 47582, 47583
Item No. Description
AM463 Electrical Box for 47582, 47583
47582
47583
Description Position
Belt A37 1/2 for 47582, 47583 1
Screw STEI M6x10 for 47582, 47583 2
Position Item No. Description
1 AM457 Washer D.6x20 SP.3 for 47582, 47583
2 AM255 Screw TE M6x20 Zinc for 47582, 47583
3 AM323 Screw TE M8x25 Zinc for 47582, 47583
Flange Support D.20 UFL 004 for 47582,
4 AM458
47583
5 AM459 Pin Lever Roller for 47582, 47583
Position Item No. Description
Motor Protection 230/3/50-60 Volt 2.5-4A
1 AM464
for 47582, 47583
Parts Breakdown
60 Hz Pulley Group
Item No. Description
AM331 Pulley 60x1A (60 Hz) for 47582, 47583
AM452 60Hz Pulley Group for 47582, 47583
Rounding Lever Group
Position Item No.
6 AM460
7 AM461
8 AM239
9 AM462
10
Position Item No.
2 AM465
29
Position
3
Description Position
Screw STEI M8x10 for 47582, 47583 11
Screw STEI M8x10 for 47582, 47583 12
Nut M8 Zinc for 47582, 47583 13
Rounding Lever Group for 47582, 47583
Electrical Group
Description Position
Protection for 47582, 47583 3
