Omcan BE-IT-0015M Instruction Manual page 27

Model BE-IT-0015M
Model BE-IT-0030M
Item No. Description
AM208 Seeger Ring D.16 for 47582, 47583
AM435 Pin Lever Roller for 47582, 47583
AM210 Nut M8 Inox for 47582, 47583
AM183 Nut M6 Inox for 47582, 47583
AM205 Latch Insert KU 16 15 for 47582, 47583
AM218 Screw TE M8x35 Inox for 47582, 47583
AM217 Plug D.8x30 for 47582, 47583
Item No. Description
AM231 Nut M16 Zinc for 47582, 47583
AM232 Washer D.16 Zinc for 47582, 47583
AM233 Non-Slip Foot for 47582, 47583
Screw TCEI M12x45 Zinc for 47582,
AM240
47583
Item No. Description
AM441 Angular Panel for 47582, 47583
AM442 Front Panel for 47582, 47583
AM443 Rear Panel for 47582, 47583
47582
47583
Position Item No. Description
1 AM216 Pin Ring Lever for 47582, 47583
2 AM212 Sliding Shoe 12x12x45 for 47582, 47583
3 AM213 Lever Lift Ring for 47582, 47583
4 AM185 Screw STEI M6x50 Inox for 47582, 47583
5 AM186 Selflocking Nut M6 Inox. for 47582, 47583
6 AM187 Screw TE M6x25 Inox for 47582, 47583
7 AM214 Spring for 47582, 47583
Position Item No. Description
1 AM234 Screw TE M8x16 Zinc for 47582, 47583
2 AM235 Wheel D.80x30 Fix for 47582, 47583
Semiautomatic Head Plate for 47582,
3 AM437
47583
4 AM438 Frame for 47582, 47583
Position Item No. Description
1 AM444 Lateral Panel for 47582, 47583
2 AM445 Power Supply Panel for 47582, 47583
3 AM246 Lock for 47582, 47583
Parts Breakdown
Operate Ring Group
Position Item No.
8 AM209
9 AM219
10 AM220
11 AM261
12 AM436
13
14
Position Item No.
5 AM239
6 AM439
7 AM440
8
Position Item No.
4 AM248
5 AM249
6 AM446
27
Description Position
Lift Ring Rod for 47582, 47583 15
Selflocking Nut M8 Inox for 47582,
16
47583
Washer D.8 Inox for 47582, 47583 17
Screw TCEI M6x25 Inox for 47582,
18
47583
Operate Ring Group for 47582, 47583
Frame Group
Description Position
Nut M8 Zinc for 47582, 47583 9
Fixing Bracket for 47582, 47583 10
Frame Group for 47582, 47583
Casing Group
Description Position
Aluminum Rivet for 47582, 47583 7
Screw Poeliers M6x12 ZNT for 47582,
8
47583
Casing Group for 47582, 47583
