II. Network diagram
Figure 4-1 Network diagram for FTP configuration
III. Configuration procedure
1) Configure the following FTP server–related parameters on the PC: an FTP user
with the username as switch and password as hello, who is authorized with the
read-write right on the directory Switch on the PC. The detailed configuration is
omitted here.
2) On the switch, configure a level 3 telnet user with the username as user and
password as hello. Authentication mode is by user name and password.
Note:
Refer to the "Login Operation" part of this manual for configuration commands and
steps about telnet user.
3) Execute the telnet command on the PC to log into the switch. The following
prompt appears:
<Sysname>
Caution:
If the Flash memory of the switch is not sufficient, delete the original applications before
downloading the new ones.
4) Initiate an FTP connection with the following command in user view. Enter the
correct user name and password to log into the FTP server.
<Sysname> ftp 2.2.2.2
Trying ...
Press CTRL+K to abort
Connected.
220 WFTPD 2.0 service (by Texas Imperial Software) ready for new user
User(none):switch
