UG-AD7656-1/57-1/58-1
6. There are four tabs available displaying the data in different
formats, this are listed here and described in more detail
later.
a. Waveform tab
b. Histogram
c. FFT
d. Summary
7. Select the number of samples to analyze.
8. "Sample" : to perform a single capture.
9. "Continous" : to perform a continuous capture from the
ADC. Press a second time to stop sampling
10. This LED indicates when a read is in progress from the
EVAL-SDP-CB1Z board.
11. Channel display buttons. Use these to display multiple
channel reads on the display. NOTE. For FFT analysis
select only one channel
Within any of the Chart panels, the following tools allow user
control of the different chart displays.
Is used for controlling the cursor if present
Is used for zooming in and out.
Is used for panning.
