Christie MPL15 Installing

Installing the MPL15
wall mount trim kit on
55" LCD display panels
Add the MPL15 wall mount trim kit as a border to tiled arrays of 55" Extreme Series display panels
that are mounted on MPL15 wall mounts.
The trim kit can cover a gap between the mounting surface and panel of 182.5 mm.
For improved ventilation behind the display panels Christie recommends only installing the trim kit along
the bottom and sides of the array.

Required parts

Each trim kit contains the following parts.
• Long trim kit pieces (P/N: 135-134109-XX, Qty. 2)
• M3x6 round head screws–PHPN 06023 (Qty. 18)
• M4x6 round head screws–PHPN 06023 (Qty. 16)
• Trim kit brackets (Qty. 4)
• Short trim kit pieces (P/N: 135-135100-XX, Qty. 2)
• M3x6 round head screws–PHPN 06023 (Qty. 6)
• M4x6 round head screws–PHPN 06023 (Qty. 8)
• Trim kit brackets (Qty. 2)

Required tools

Ensure the appropriate tools are available during the installation.
• #2 Phillips screw driver

Related documentation

Additional information on the LCD panels and wall mounts is available in the following documents.
• Installing Flat Panels on the MPL15 Wall Mount Instruction Sheet (P/N: 020-102543-XX)
• FHD553-X User Manual (P/N: 020-001649-XX)
• FHD553-XE and FHD553-XE-H User Manual (P/N: 020-001183-XX)
Installing the MPL15 Wall Mount Trim Kit on 55" LCD Display Panels Instruction Sheet
020-102862-03 Rev. 1 (05-2020)
Copyright © 2020 Christie Digital Systems USA, Inc. All rights reserved.
1
