Power source
Working voltage DC 8.2 -16V
Idling current 1.45A
Standby current 5.8mA
8.2 - 16V
REM input voltage
DC12V (0.5A)
REM output voltage
Signal Processing
THD @1kHz, 1V Rated power output 0.02%
Band width @-3dB 2 0 - 20KHz
S/N Ratio @ 1W(AMP) 75dB (A-weighted)
S/N Ratio @100W(AMP)/20W(AMP) 88dB (A-weighted)
S/N Ratio @ 1V(Pre out) 85dB (A-weighted)
Channel Separation @ 1 kHz >70dB
Input sensitivity (AUX IN ) 0.2V - 2V
Input sensitivity (high level) 0 .4V - 10V
Input impedance l ow level:22KΩ / high level:10Ω
Maximum output level (RMS) @ 0.1% THD 3.5V
Input/output
AUX input 2 channel
High level input Up to 8 channel
Bluetooth/optical/DSD signal input Stereo
Low level (PRE) RCA output Up to 12 channel
4Ohm( stereo) power @1% THD Class AB 4 x 20 Wrms + Class D 8x100Wrms
2Ohm( stereo) power @1% THD 4 x 170Wrms(CH9/10/11/12 only)
4Ohm( bridged) power @1% THD 2 x 350Wrms (CH9/10/11/12 only)
Crossover Filter type Full/High pass/Low pass/Band pass
Filter mode and slope
Linkwitz 12/18/24/30/36/42/48 dB
Butterworth 6/12/18/24/30/36/42/48 dB
Input/output crossover 10 - 20KHz,increments 1Hz
Phase adjustment 0° / 180°
Dimension Length x Width x Height 229 x 203 x 53mm
