- Page 1 XC-5000.1 XC-1500.2 XC-1000.4 XC-2500.5 COMPETITION AMPLIFIERS XC SERIES installation and operation...
-
Page 2: Before You Begin Installation
XC-1000.4 is 1ohm stereo or 2ohm bridged, for XC-2500.5 is CH1-4 ( 2ohm srereo or 4ohm bridged ) and CH5 is 1ohm stable. FOR-X amplifiers are not equipped with fuses so that proper value of external fuses should be used. The fuse ratings should be sufficient under normal working conditions. However, if the amplifiers are overloaded fuses may blow. - Page 3 Connect the power cables to power terminal + 12V. All XC series amplifiers do not have built-in fuses so they need external fuse connection. Connect one end of fuse holder to the power cable going into the amplifiers and the other end of fuse holder to positive battery.
- Page 4 XC-5000.1 Speaker connection 4 - 1ohms Caution !! XC-5000.1 minimum working impedance is 1ohm or 2ohm strapable. Impedance lower than 1 ohm can damage the amplifier 4 - 2ohms 4 - 2ohms...
- Page 5 XC-5000.1 Strapable connection Strapable connection makes two of same amplifiers linked to 2ohm. Strapable connection makes the power double than their each 1ohm power. Please read the following connection and diagram carefully to make correct connection. Strapable input connection Step 1. Connect the Master amplifier to the head-unit and set its output master / input slave switch to output master.
- Page 6 Strapable speaker connection Step 1. Connect speaker cable ( ) on master ampli er to subwoofer ( ) Step 2. Connect speaker cable ( ) on slave ampli er to subwoofer ( ) Step 3. Connect speaker cable ( ) on master ampli er to speaker cable ( ) on slave ampli er MASTER AMPLIFIER Connect negative of master amplifier’s terminal to negative of slave amplifier’s terminal...
- Page 7 XC-1500.2 Speaker connections 4 - 1ohms 4 - 1ohms Caution !! XC-1500.2 minimum working impedance is 1ohm stereo or 2ohm bridged. Impedance lower than 1 ohm stereo can damage the amplifier Mid-range Mid-range Tweeter Tweeter Crossover Crossover 4 - 2ohms...
- Page 8 XC-1000.4 Speaker connections Mid-range Mid-range Tweeter Tweeter Crossover Crossover Crossover Crossover Tweeter Tweeter Mid-range Mid-range Caution !! XC-1500.2 minimum working impedance is 1ohm stereo or 2ohm bridged. Impedance lower than 1 ohm stereo can damage the amplifier Mid-range Mid-range Tweeter Tweeter Crossover Crossover...
- Page 9 XC-2500.5 Speaker connections Mid-range Mid-range Tweeter Tweeter Crossover Crossover Caution !! XC-2500.2 minimum working impedance is 2ohm stereo or 4ohm bridged for CH1- CH4 and 1ohm for CH5 Impedance lower than 2ohm stereo for CH1-4 and 1ohm for CH5 can damage the amplifier Mid-range Mid-range Tweeter...
-
Page 10: Troubleshooting
TROUBLE SHOOTING NO POWER LED ON, NO OUTPUT Check +12V and GND connection Check remote signal +12V Check the external fuses or built-in. POWER LED ON, NO OUTPUT Check source unit for output Check input gain control Check RCA cable Check speaker and wiring for shorts Check for damaged speakers NO SOUND ON ONE CHANNEL... -
Page 11: Specification
SPECIFICATION XC-5000.1 XC-1500.2 XC-1000.4 XC-2500.5 Features 4ohm RMS power 1700W x 1 650W x 2 500W x 4 130W x 4 + 680W x 1 2ohm RMS power 2900W x 1 1100W x 2 800W x 4 200W x 4 + 1100W x 1 1ohm RMS power 5000W x 1 1500W x 2... - Page 12 COMPETITION AMPLIFIERS XC SERIES...
