- Page 1 Owner’s Manuel XQ-4860DSP Digital Signal Processor Amplifier...
-
Page 2: Packing List
Please contact with professional engineer for checking to avoid accident happen. Packing List For every package including below items, Please noticed retailer and Factory if shortage: XQ-4860DSP unit User Manual USB computer tuning cable 1PCS Head unit Cable... -
Page 3: Table Of Contents
Contents User Manual Mobile Application Instructions....................1-4 1. Features 1.1 Audio specification、main audio signal process diagram…….…..5 1.2 Input and output side panel………..…………………………………....…...6 1.3 Software Introduction……………………………….…………........6 1.4 Function Introduction…………………………………………........7 2. Installation 2.1 System classic connecting reference………..……...…..…….…………...8 2.2 Unit connection..……………….………….……..…….…...........9 Low level RCA input/output………………………………………......9 USB2.0 Port……………….…..………………….………........10 3. -
Page 4: Mobile Application Instructions
Mobile Application Instructions Main volume adjustment Android mobile scan Qrcode on gift box to download the application to install XQ-4860DSP ● The main volume can be adjusted by app. Turn on the unit and plug in external pressing the main volume scale clockwise or counterclockwise by hand. -
Page 5: Connection Status
Click【EQ】to enter EQ interface Equalization settings 1、Click 【 Reset EQ 】 to restore the parameters of the 31-band equalizer to the original. pass-through mode (the equalizer frequency, Q value and gain are restored to their initial values). XQ-4860DSP I DSP amplifier... -
Page 6: Channel Settings
,Q value and CH1 to CH8 speakers. Frequency settings, as shown in Figure XQ-4860DSP I DSP amplifier... -
Page 7: Mixer Settings
Perform to select lossless music playback/ Click [ ] Enter the menu at the upper left pause/previous/next song corner, It can Perform for Encryption/input Source volume /boost source/Noise gate/Reset to factory default /about /exit etc setting. XQ-4860DSP I DSP amplifier... -
Page 8: Audio Specification、Main Audio Signal Process Diagram
Low level Low level Low level Low level Low level Low level Low level Low level Output 1 Output 3 Output 4 Output 5 Output 6 Output 7 Output 8 Output 2 XQ-4860DSP I DSP amplifier... -
Page 9: Input And Output Side Panel
9.) Low level RCA output 10.) Speaker output 1.3 Software Introduction XQ-4860DSP PC software control: (please check 3. Software Operation detail ) 1) Autometically detect whatever the hardware is connecting with USB cable, if ready and will connect with head unit autometically. -
Page 10: Function Introduction
Each output channel can be adjusted for phase and time Output phase and delay, parameter range time delay Phase: 0 ゜/180 ゜ Time delay: 0.000-20.0ms，0.00-692cm，0.00-273inch Scene operations Unit can keep 6-style of music scenes by preset. XQ-4860DSP I DSP amplifier... -
Page 11: System Connections
Figure 2.1 this connecting method is for two units input, please refer below: 1. Please use Plug & Play cable to connect original car unit and XQ-4860DSP for upgrade audio system effects. Please use OUT7 and OUT8 RCA output when Install bass amplifier or subwoofer 2. -
Page 12: Unit Connection
OUT6 are NULL, while the default output type of CH7 and CH8 is ultra-low left and ultra-low right, usually external bass amplifier, as bass strengthened. Of course, users can configure their own initiative RCA low level output to complete more high-end divided by two or three-way system. XQ-4860DSP I DSP amplifier... -
Page 13: Usb2.0 Port
As shown in figure 1.2.1, the "8" indicator bit is the "USB2.0" position. Figure 2.3 Use Random accessories USB cable into this hole on a computer connected to the PC, open tuning software to debug the sound system. XQ-4860DSP I DSP amplifier... -
Page 14: Software Operation
XQ-4860DSP provides only wired USB PC software connection. Wired USB connection: Ensure that XQ-4860DSP power state, with a USB cable to connect to a computer through the USB interface, the computer will find the new device and automatically install the update equipment, after a few seconds the installation is complete. -
Page 15: Software Interface
User Manual 3.3 Software interface Figure 3.2.2 Software interface XQ-4860DSP unit divided into the following functional: 1．as shown in figure 3.2.2, "1", input signal selection: high level,Bluetooth, Optical,RCA,Player. 2．as shown in figure 3.2.2 "2", shows the main menu and connection status. -
Page 16: Output Voice, Delay, Type, Mute And Phase Setting
Select delay units, which are in milliseconds, centimetres, and inches. The range of milliseconds: 0.000~20; Range of mm: 0~692; Range of inches: 0 to 273; XQ-4860DSP processor output signal path can be any type of configuration freedom to any sound field point and the speaker type. The system defaults to... -
Page 17: Output Switch
Figure 3.3.5 as follows: Figure 3.3.5 The system will be based on the user has selected the type of output signal path, the shielding portion of the signal path type option (as a shadow, the user is not XQ-4860DSP I DSP amplifier... - Page 18 (Figure 3.3.７) Low Shelf/High Shelf adjustment Click on the left or right side of the "Low Shelf/High Shelf" button at the bottom to adjust the frequency. XQ-4860DSP I DSP amplifier...
-
Page 19: Output Signal Equalizer And Crossover Operation
Straight balanced: the button shown in Figure 3.3.4, the current channel as long as there is an equalizer in the open state, this button will appear highlighted in green state, indicating that you can click this button to make all the equalizer XQ-4860DSP I DSP amplifier... -
Page 20: Output Signal Function Operation
20Hz ~ 20KHz. Slope(slope)settings:6dB/Oct,12dB/Oct,18dB/Oct,24dB/Oct,30dB/Oct,36dB/Oct, 42dB/Oct, 48dB/Off/Oct and other 9 options. Note: In 6dB / Oct, there is no type of algorithm, but a common type (displayed as NULL). 3.3.5 Output signal equalizer and crossover operation figure 3.3.10 XQ-4860DSP I DSP amplifier... - Page 21 (Figure3.3.11): figure 3.3.11 Mixer settings: click "mixer" in the "7" area in Figure 3.2.2, then you can switch to (Figure3.3.14) the relevant parameter settings for the corresponding adjustment. figure 3.3.14 XQ-4860DSP I DSP amplifier...
-
Page 22: Setting Introduce
User Manual 3.4 Setting introduce Figure 3.4.1 As shown in Figure 3.4.1 XQ-4860DSP software of the scene in three major types of actions: the machine stored scene data, computer data stored scene and the whole scene data manipulation. 1．the machine data stored scene operation: refers to the scene data is now running... - Page 23 (Figure 3.4.3). Figure 3.4.3 Step3: as dialog box of figure 3.4.3 , select the machine where the user wants to load a preset number (as selected on the 3rd), and then point below the "Load" button on XQ-4860DSP I DSP amplifier...
-
Page 24: Load And Save To Store Scene Files On Your Computer
2.loading scene files on your computer This function is previously stored in the scene file on the computer the machine work load for the current scene step1: Click on the main interface to the top menu "File" button will pop up XQ-4860DSP I DSP amplifier... -
Page 25: Load And Save The Whole Store A Scene
We recommend similar models when making audio system, for the whole replication functions. The specific operation method is basically the same as "loading the scene file on the computer", please refer to the operation by yourself. XQ-4860DSP I DSP amplifier... -
Page 26: Operations Introduction
Figure 3.5.1. Figure 3.5.1 3.5.2 Source Volume Setting In the options menu, click the "Source Volume" option with the mouse, and a message dialog box will pop up, in which you can set the volume for XQ-4860DSP I DSP amplifier... -
Page 27: Information About The Inquiry
3.5.5 Lock Setting In the options menu, click the "Lock" option with the mouse, and a message dialog box will pop up, in which you can set the password for encryption. shown in Figure 3.5.5。 Figure 3.5.5 XQ-4860DSP I DSP amplifier... -
Page 28: Common Trouble Shouting
1. pls check if turn on mute style No voice 2. pls check if input channel is correct? 1. pls check if USB cable is setting correct cannot link USB 2. pls cehck if find name as “ HID-compiling device”in the computer XQ-4860DSP I DSP amplifier... - Page 29 www.for-x.com.tr...
