For-x XD-180.2 User Manual

XD-180.2
Two-Channel Full Range Class D Amplifier
User's Manual
Please read this manual thoroughly to before you install it.

Introduction:

Congratulations on your purchasing a high quality amplifier!
The amplifiers are manufactured with advanced craftsmanship and using the highest quality components and strict
quality control system. Thanks for your trust on FOR-X brand! Maintain your amplifier properly and it will ensure
you uncompromising musical enjoyment.
XD-180.2
The FOR-X class D amplifier is designed to revivify the high quality of the video in optimum sound systems.
It will display the high quality sound efficiently and reduce the dissipation to minimum.
Those RCA input can receive various of stereo signals and signals from CD/MP3 player also.

Read before installation

Please read this manual thoroughly. Below are the information which are very important for you to ensure you install
properly. If necessary, please contact with the after selling service department to solve the questions.
Please use high quality cables and keep them as short as possible, avoiding electrical disturbances and too hot.
The amplifier GND terminal should connect to the minus terminal of the battery directly .
Locate the position on the chassis o the car to which amplifier is to be ground.
To be safe, all cables should lay flat on the car chassis. Route the RCA cables away from other current carrying cables,
electronic power, auto ignition, key inject.
The +12 Volt power cable must be connected with a fuse in line within 30 cm from the battery +12 terminal, as show
in the attachment 02.
The install position is very import, it must be far from vibration source. It is better to install on top of speaker box. Do
not install it on module. Heating dissipation and air exhausting are very important to when install it on auto chassis.

Installation examples:

SUBWOOFERS/4Ω(200W)
XD-180.2-1
