  • Page 1 OPERATION AND INSTALLATION Integral cylinder » HSBC 300 cool (GB) (WPM)

  • Page 2: Table Of Contents

    CONTENTS SPECIAL INFORMATION 17.5 Energy consumption data  29 17.6 Data table  29 OPERATION 17.7 Accessories  30 General information �����������������������������������������3 GUARANTEE Relevant documents 3 Safety instructions  3 ENVIRONMENT AND RECYCLING Other symbols in this documentation  4 Information on the appliance  4 Units of measurement  4 Safety ����������������������������������������������������������4...

  • Page 3: Special Information

    SpECial iNfOrmaTiON General information SpECial iNfOrmaTiON OpEraTiON - The appliance may be used by children over 8 General information years of age and persons with reduced physi- The chapters "Special information" and "Operation" are intended cal, sensory or mental capabilities or a lack of for appliance users and qualified contractors.

  • Page 4: Other Symbols In This Documentation

    OpEraTiON Safety Other symbols in this documentation Safety Note Intended use General information is identified by the adjacent symbol. This appliance is intended to be used for seasonal heating and f Read these texts carefully. cooling of interiors (7 °C / 12 °C) and for DHW heating. The appliance is intended for domestic use.

  • Page 5: Appliance Compatibility

    OpEraTiON appliance compatibility Appliance compatibility Cleaning, care and maintenance f Have the electrical safety of the appliance and the function The appliance can be operated in conjunction with the following of the safety assembly regularly checked by a qualified air source heat pumps: contractor.

  • Page 6: Installation

    iNSTallaTiON Safety iNSTallaTiON Pipe assembly RBS-SBC The hydraulic connections can be routed upwards at the rear of the DHW cylinder using the RBS-SBC pipe assembly available as an accessory. Safety Preparation Only a qualified contractor should carry out installation, commis- sioning, maintenance and repair of the appliance.

  • Page 7: Transport And Handling

    iNSTallaTiON preparation Transport and handling 9.2.1 Removing/fitting the front casing Removing the front casing Material losses Store and transport the appliance at temperatures be- tween -20 °C and +60 °C. Handling f Undo the 4 screws from the non-returnable pallet. f Tilt the appliance and screw the 4 adjustable feet into the appliance.
  • Page 8 iNSTallaTiON preparation 9.2.2 Overview of insulation segments 1 Insulation segment 1 2 Insulation segment 2 3 Insulation material screw 4 Insulation segment 3 | HSBC 300 cool www.stiebel-eltron.com...
  • Page 9 iNSTallaTiON preparation 9.2.3 Separating / joining the appliance sections Separating the appliance sections Material losses Unscrewing the fastening screws destroys the threads in the insulation segment. f To open the 3 fixing tabs, loosen the fastening screws slightly but do not unscrew them completely. f Pull the "heating sensor"...
  • Page 10 iNSTallaTiON preparation f Remove the 4 hydraulic hoses. f Pull the upper section of the appliance towards the front. f Remove the 2 insulation material screws. f Remove insulation segment 3. f Undo the 2 locking screws on the side profile strips. 1 Handle f Lift up and unhook the side profile strips.
  • Page 11 iNSTallaTiON preparation Joining appliance sections Material losses To prevent condensation forming, the insulation seg- ments must fit closely against the lower section with no gaps. f When inserting the insulation segments, ensure that the joint grooves are kept clear. f Tap the insulation segments down with your hand. Rejoin the appliance sections in reverse order.

  • Page 12: Installation

    iNSTallaTiON installation 10. Installation f Install the heating water pipes (see chapter "Specification / Dimensions and connections"). f Protect the flow and return lines against frost with sufficient 10.1 Positioning the appliance thermal insulation. f When positioning the appliance, observe minimum clearanc- f Connect the hydraulic connections with flat gaskets.
  • Page 13 iNSTallaTiON installation Preparation f Remove the front casing and insulation segment 1 (see chap- ter "Installation / Preparations / Transport and handling"). The following components are prefitted on the HSBC side at the pump assembly installation site: (*) Pipe assembly inserted 1 Profiles for 3-way mixer 2 Insulation mat for 3-way mixer 1 Insulation plugs 3 Servomotor for 3-way mixer...

  • Page 14: Dhw Connection And Safety Assembly

    iNSTallaTiON installation f Route the pump assembly connecting cable to the control 10.3.1 DHW connection and safety assembly panel as shown. f Flush the pipes thoroughly. f Slide the pipe insulation over the connection pipe connectors f Install the DHW outlet line and the cold water inlet line (see from above.

  • Page 15: Filling The System

    iNSTallaTiON installation 10.4 Filling the system Heating circuit water quality Carry out a fill water analysis before filling the system. This analy- sis may, for example, be requested from the relevant water supply utility. To avoid damage as a result of scaling, it may be necessary to soften or desalinate the fill water.

  • Page 16: Venting The Appliance

    iNSTallaTiON Electrical connection 11. Electrical connection 10.4.3 DHW cylinder filling Material losses WARNING Electrocution Some fluxes used to solder pipes and fittings need to be Carry out all electrical connection and installation work flushed out with hot water. in accordance with relevant regulations. f Heat the cylinder to its normal operating tempera- Before any work on the appliance, disconnect all poles ture and flush all pipe work with hot water to ensure...

  • Page 17: Control Voltage

    iNSTallaTiON Electrical connection f Route all power cables and sensor leads into the appliance AA01-X1.6 BT13 Temperature sensor, heat pump, flow, heating circuit 2 (HSBC 3-HKM accessory) through the cable entry. AA01-X1.8 BT20 DHW cylinder temperature sensor f Connect the power cables and sensor leads as detailed below.

  • Page 18: Accessories

    iNSTallaTiON Electrical connection Safety extra low voltage Note X1.14 Constant 12 V Analogue input 0-10 V For every appliance fault, output X2.10 issues a 230 V Input signal. X1.15 Constant 12 V Analogue input 0-10 V In the case of temporary faults, the output switches the Input signal through for a specific time.

  • Page 19: Sensor Installation

    iNSTallaTiON Commissioning 12. Commissioning f X2.1 (L), X2.2 (L*): Connect the high limit safety cut-out to the terminals. Our customer support can assist with commissioning, which is a chargeable service. 11.5 Sensor installation If the appliance is intended for commercial use, observe the rules 11.5.1 AF PT outside temperature sensor of the relevant Health &...

  • Page 20: Settings

    iNSTallaTiON Settings Setting for single-phase operation Control modes and functions Variable differential Recommended for two-pipe heating systems with radi- Note pressure ∆p-v ators to reduce flow noise at thermostatic valves On appliances with a single phase connection, set the (I, II, III) heat pump manager as follows for calculating the amount The pump reduces the delivery head by half when the flow rate in the pipework decreases.

  • Page 21: Appliance Handover

    iNSTallaTiON appliance handover 16. Maintenance Operating lED indicator Control mode Curve button WARNING Electrocution Variable differential pressure ∆p-v Carry out all electrical connection and installation work in accordance with relevant regulations. Variable differential pressure WARNING Electrocution ∆p-v Before any work on the appliance, disconnect all poles of the appliance from the power supply.

  • Page 22: Specification

    iNSTallaTiON Specification 17. Specification 17.1 Dimensions and connections HSBC 300 cool (GB) Set Entry electrical cables Cold water inlet Male thread DHW outlet Male thread DHW circulation Male thread G 1/2 T&P valve Heat pump flow Diameter Heat pump return Diameter Heating flow Diameter...
  • Page 23 iNSTallaTiON Specification Other dimensions and connections RBS-SBC 1051 1015 rBS-SBC HSBC 300 cool (GB) Set Cold water inlet Diameter h08 Sensor heat pump Diameter DHW outlet Diameter cooling, optional DHW circulation Diameter Sensor DHW Diameter Sensor, DHW, Diameter optional Sensor heating Diameter Flange External diameter...

  • Page 24: Hydraulic Diagram

    iNSTallaTiON Specification 17.2 Hydraulic diagram 1 Discharge below fixed grate 2 Cold water supply 3 Shut-off valve 4 Line strainer 5 Pressure reducing valve 6 Balanced pressure; cold water outlet 7 Check valve 8 Safety assembly 9 Tundish 10 Metal discharge pipe (D2) from tundish, with continuous fall 11 Equipotential bond 12 Drain valve 13 Cylinder...
  • Page 25 iNSTallaTiON Specification www.stiebel-eltron.com HSBC 300 cool |...

  • Page 26: Wiring Diagram

    iNSTallaTiON Specification 17.3 Wiring diagram HSBC 3-HE (Zubehör) (X2.11) Steuerspannung XD03.1 XD06.1 XE01 L’ GNYE XD06.2 BU (com.) Deckelblech/ BN (PWM IN) Top cover MA14 Vorderwand/ Front cover GNYE BU BN BU BN GNYE MA10 MA11 KF 17 MA19 MA15 | HSBC 300 cool www.stiebel-eltron.com...
  • Page 27 iNSTallaTiON Specification L‘ BT06 BT13 BT20 BU BN MA11 BN (PWM IN) BU (com.) 1 = H AA06 2 = L  4 = +12V    AA01 (WPM) www.stiebel-eltron.com HSBC 300 cool |...
  • Page 28 iNSTallaTiON Specification AA01 WPM heat pump manager AA01 X2.15 Connector, mixer, heating circuit 3 (X2.15.1 Mixer OPEN/X2.15.2 Mixer CLOSE) AA06 Programming unit AA06 Terminal, programming unit BT06 Temperature sensor, heat pump buffer cylin- AA07 Connector, temperature sensor, heat pump flow BT01 BT13 Temperature sensor HP flow HC2 (accessories HSBC 3-HKM)

  • Page 29: Data Table

    Max. permissible pressure (design pressure), heat HSBC 300 cool (GB) Set exchanger, top 204651 Test pressure, DHW cylinder 1.50 Manufacturer STIEBEL ELTRON Max. flow rate l/min Supplier's model identifier HSBC 300 cool (GB) Set Max. permissible pressure (design pressure), buff- Energy efficiency class...

  • Page 30: Accessories

    iNSTallaTiON Specification HSBC 300 cool (GB) Set Values Nominal heating flow rate at A-7/W35 and 7 K m³/h Min. flow rate, heating m³/h Safety assembly, max. supply pressure Recommended operating pressure, heating circuit Recommended operating pressure, DHW 0.35 Pressure reducer, set value 0.35 T&P valve, nominal set temperature °C...
  • Page 31 GUARANTEE | ENVIRONMENT AND RECYCLING Guarantee The guarantee conditions of our German companies do not apply to appliances acquired outside of Germany. In countries where our subsidiaries sell our products a guarantee can only be issued by those subsidiaries. Such guarantee is only grant- ed if the subsidiary has issued its own terms of guarantee.
