  • Page 1 OPERATION AND INSTALLATION Integral cylinder » HSBC 300 cool (AU)

  • Page 2: Table Of Contents

    Maintenance ������������������������������������������������ 21 Specification ������������������������������������������������ 22 15.1 Dimensions and connections  22 15.2 Wiring diagram  24 15.3 Hydraulic diagrams  26 15.4 Data table  26 15.5 Accessories  27 GUARANTEE ENVIRONMENT AND RECYCLING | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 3: General Information

    Failure to observe this information will result in serious injury or death. WARNING Failure to observe this information may result in serious injury or death. CAUTION Failure to observe this information may result in non-seri- ous or minor injury. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 4: Safety

    Material losses The system's active frost protection is not guaranteed if the power supply is interrupted. f Never interrupt the power supply even outside the heating season. Test symbols See type plate on the appliance. | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 5: Cleaning, Care And Maintenance

    Check the taps regularly. Limescale deposits at the tap out- lets can be removed using commercially available descaling agents. f Regularly activate the safety valve to prevent it from becom- ing blocked, e.g. by limescale deposits. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 6: Installation

    The hydraulic connections can be routed upwards at the rear of the DHW cylinder using the RBS-SBC pipe assembly available as an accessory. The minimum side clearances can be swapped between left and right. | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 7: Transport And Handling

    Unhook the front casing towards the top. the upper and lower sections of the appliance as described in the f Remove the earth cable from the front casing. following chapters. f Fit the front casing in reverse order. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 8: The Appliance May Be Used By Children Over

    9.2.2 Overview of insulation segments 1 Insulation segment 1 2 Insulation segment 2 3 Insulation material screw 4 Insulation segment 3 | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 9 Disconnect the push-fit connectors of the 4 hydraulic con- nections. To do this, pull the spring clips fully out with a screwdriver. f Pull the hydraulic connectors as indicated. f Remove insulation segment 1. f Remove insulation segment 2. www.stiebel-eltron.com HSBC 300 cool (AU) |...
  • Page 10 Tip the upper section of the appliance backwards. Use the handle for improved grip. f Release the 4 screws on the tabs at the front of the appliance. f Place the upper section of the appliance on a base to prevent damage. | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 11 Insert the "heating sensor" into the buffer cylinder. f Lay the sensor lead in the guide groove provided for this purpose. f Fit insulation segment 2. f Fit insulation segment 1. f Fit the front casing. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 12: Installation

    Material losses The products of corrosion (e.g. rusty sludge) can set- tle in the heating system components, which may re- sult in a lower output or fault shutdowns due to reduced cross-sections. | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 13 Counterhold and unscrew the dummy caps from the 5 3-way mixer (*) adaptors. 6 Insulation mat for 3-way mixer 7 Flat gaskets 8 Servomotor for 3-way mixer (*) 9 Insulation mat for 3-way mixer and heating circuit pump (*) Pipe assembly www.stiebel-eltron.com HSBC 300 cool (AU) |...
  • Page 14 Slide the pipe insulation over the connection pipe connectors from above. (*) Pipe assembly inserted 6 Insulation mat for 3-way mixer 8 Servomotor for 3-way mixer 11 Profiles for 3-way mixer | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 15 Insert the insulation mat on the HKM side for the 3-way mixer and the heating circuit pump. “+” “-” XD04 f Wire up the heating circuit pump and 3-way mixer (see chap- ter "Installation / Electrical connection / Control voltage"). www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 16: Dhw Connection And Safety Assembly

    DHW circulation connection (see chapter "Specifi- cation / Dimensions and connections"). f Remove the sealing cap from the DHW circulation connection (see chapter "Specification / Dimensions and connections"). f Connect the DHW circulation line. | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 17: Venting The Appliance

    Detach the vent hose from the hose attachment. f Hang the free end of the vent hose in a container. f To ventilate, open the air vent valve. f After ventilation, close the air vent valve. f Secure the vent hose. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 18: Control Voltage

    At terminals XD03.2 HKP/MKP, you can install a tempera- ture limiter for the underfloor heating system by remov- ing the jumper between L and 2. XD03.3 Control terminal Mixer Mixer, servomotor, heating circuit 2 Diverter valve, heating/DHW | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 19: Safety Extra Low Voltage

    WPM heat pump manager. f Lay the sensor lead in the guide groove provided for this pur- pose in the insulation segment. f Connect the temperature sensor to T(KUE) of terminal XD04 of the appliance. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 20: Commissioning

    The pump runs at three preset fixed speed levels (I, II, Constant speed III). Note Factory setting: (*) Pressing the button for the 9th time in succession returns the Constant speed, curve III Q/m³/ h system to the factory setting (constant speed, curve III). | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 21: Appliance Handover

    WARNING Electrocution Before any work on the appliance, disconnect all poles of the appliance from the power supply. Draining the buffer cylinder f Drain the buffer cylinder via the drain valve. www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 22: Specification

    Cold water inlet Male thread DHW outlet Male thread DHW circulation Male thread G 1/2 T&P valve Female thread Rp 3/4 Heat pump flow Diameter Heat pump return Diameter Heating flow Diameter Heating return Diameter | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 23 Sensor DHW Diameter Sensor, DHW, optional Diameter Sensor heating Diameter Flange External diameter Torque Protective anode Female thread G 1 1/4 15.1.1 HSBC 3-HKM accessories HSBC 3-HKm Heating flow, mixed Diameter Heating return, mixed Diameter www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 24: Wiring Diagram

    Specification 15.2 Wiring diagram | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 25 Control terminal (mains buffer charging pump) XD03.2 Control terminal (heating circuit pump, pump heating circuit 2) XD03.3 Control terminal (mixer heating circuit 2, diverter valve) KF17 Relay, diverter valve, heat source XE03 Earth terminal, control unit www.stiebel-eltron.com HSBC 300 cool (AU) |...

  • Page 26: Hydraulic Diagrams

    < 0.1 Power consumption Max. power consumption, charging pump Max. power consumption, circulation pump on the heating side Energy data Standby energy consumption/24 h at 65 °C 1.50 Electrical data Frequency Versions IP rating IP20 | HSBC 300 cool (AU) www.stiebel-eltron.com...

  • Page 27: Accessories

    Height when tilted 2123 Weights Weight, full Weight, empty Further details HSBC 300 cool (AU) 202126 Maximum altitude for installation 2000 15.5 Accessories Pump assembly HSBC 3-HKM HSBC 3-HKm 238825 Connections Heating circuit connection www.stiebel-eltron.com HSBC 300 cool (AU) |...
  • Page 28 Who gives the warranty where our subsidiaries sell our products a guarantee can only The warranty is given by Stiebel Eltron (Aust) Pty Ltd be issued by those subsidiaries. Such guarantee is only grant- (A.B.N. 82 066 271 083) of 294 Salmon Street, Port Mel- ed if the subsidiary has issued its own terms of guarantee.
  • Page 29 The Stiebel Eltron warranty for the unit is in addition to any f) connection to water from a bore, dam or swimming rights and remedies you may have under the Australian pool;...
  • Page 30 NOTES | HSBC 300 cool (AU) www.stiebel-eltron.com...
  • Page 31 NOTES www.stiebel-eltron.com HSBC 300 cool (AU) |...
  • Page 32 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
