- Page 1 06-12-2022 INS190 Anson - Circular Table ANS-TBC12 ASSEMBLY Pack 1: Pack 3: INSTRUCTIONS Top Pack Corner Kit Anson Circular Table Pack 2: Pack 4: Leg Kit Rail Kit...
- Page 2 **mm **mm 1,2,3...
- Page 3 Please check that you have all the panels HN-TAB-LEG-KIT ANS-TBC12-TOP PACK 1: PACK 2: 1 x Top Panel 1 x Leg Kit HN-CAST HN-TAB-X-RAIL-KIT PACK 3: PACK 4: 1 x Corner Kit 1 x Rail Kit Please check that you have all the fittings FITTINGS SUPPLIED M6 Connector Bolt Adjustable Foot...
- Page 4 ANSON CIRCULAR TABLE ASSEMBLY Step 1 Unpack your Anson circular table and please recycle all packaging. Place the top face down so that the fixing holes are face-up. image ‘a’. image ‘b’. Step 2 Assemble the legs as per ‘image a’ using parts from leg kit &...
