- Page 1 19-12-2022 INS189 Anson - Executive Bookcase ANS-MBK ASSEMBLY Pack 1: Pack 3: Top & Base Pack Side Pack INSTRUCTIONS AN-MBK-TBAS AN-MBK-SID Anson Executive Bookcase Pack 2: Back Pack AN-MBK-BCK...
- Page 2 **mm **mm 1,2,3...
-
Page 3: Fittings Supplied
Please check that you have all the panels AN-MBK-TBAS AN-MBK-SID PACK 1: PACK 2: 1 x Top, Base & Shelf Pack 1 x Side Pack AN-MBK-BCK PACK 3: 1 x Back Pack Please check that you have all the fittings FITTINGS SUPPLIED Quick-fit Pin Quick-fit Cam... - Page 4 ANSON BOOKCASE ASSEMBLY Step 1 Unpack your Anson bookcase packs and please recycle all packaging. Step 2 Pre-assemble the fittings to all the side, back top & base panels as shown. Step 3 Assemble the back & sides by aligning the pins in the sides with the cams located in the back panel as shown.
- Page 5 ANSON BOOKCASE ASSEMBLY Step 4 Position the top and base and again aligning the pins in the top and base with the cams located in the back & side panels as shown. Tighten the cams on the back & side panels by turning them clockwise.
