- Page 1 01-21-2019 Elev8 Touch - Return Desk EVT-RET EVT-1200 EVT-1400 EVT-1600 Pack A: ASSEMBLY 1 x DESKTOP Pack B: INSTRUCTIONS 1 x UNDER FRAME Pack C: Elev8 Touch 1 x RETURN FRAME Return Desk Pack D: 1 x RETURN TOP...
- Page 2 1 x Pozi screwdriver 1 x 4mm Allen key 1 x 5mm Allen key 1,2,3...
-
Page 3: Fittings Supplied
Please check that you have all the components PACK A: 1200mm = ED128T 1 x DESKTOP 1400mm = ED148T 1600mm = ED168T PACK B: Leg pack code = ST-T-* 1 x UNDER FRAME PACK C: Return frame code = RT-KIT-* 1 x RETURN FRAME PACK D: Return top code = EDRT... - Page 4 ELEV8 TOUCH RETURN DESK ASSEMBLY Step 1 Unpack your new height adjustable desk frame and place on a flat surface. Return desk leg Single desk frame Step 2 Attach the cross rails to the return leg using the M6 machine thread bolts. Step 3 Attach the control box to the frame positioned between...
- Page 5 Step 4 Slide off the leg with the pre- attached control box and replace Standard leg it with the return leg. Return leg Step 5 Unfold both legs to their upright position. Step 6 Insert the 2 desktop end rails into the frame cross sections.
- Page 6 Step 7 Once the end rails have been inserted into the cross rails, tighten the 4 bolts at points A-D. Step 8 Attach both of the larger feet to the leg uprights using the 8 x bolts provided Step 9 Once the feet are attached, turn the desk over into its upright position.
- Page 7 Step 10 Assemble the remaining leg by firstly unfolding the leg upright into its vertical position. Step 11 Insert the remaining end rail into the frame cross sections and tighten at points A & B. Step 12 Attach the smaller foot to the leg upright with the remaining 4 x bolts provided.
- Page 8 Step 13 Insert the remaining cross rails into the leg and tighten the grub screws at the required length. Step 14 Now the return leg has been assembled turn the leg over into its upright position. If you cannot lift the leg, seek assistance as not to cause injury or damage to the product.
- Page 9 Step 15 Attach the return leg to the main desk frame and tighten the grub screws in the rails. Extend the frame to your desired length (1200mm, 1400mm or 1600mm). Right hand return Left hand return...
- Page 10 Step 16 Extend the frame to your desired length (1200mm, 1400mm, 1600mm). Once extended, tighten the grub screws on the inside face of the cross sections. Step 17 NOTE Now that your desk frame is Before proceeding, ensure assembled you can proceed with that the connector plugs are the wiring.
- Page 11 Step 18 Connect the extender cable to the remaining connector on the return leg. Insert connector into port “M3” on the control box. Step 19 You can now attach the desktop controller. This connector plug should be inserted into the port marked “H”...
- Page 12 Step 20 The desktop controller should be positioned on the opposite side of the desk to the return. Insert the wire protector into the recessed cut out in the top of the cross section and ensure the wire passes through the protector.
- Page 13 NOTE Step 22 Use Ø5 x 20mm wood screws to attach the top to the frame. Now position the desktop onto the framework ensuring that the scalloped edge is at the rear of the frame. Align the holes in the desktop end rails with the pre drilled holes on the underside of the desktop.
- Page 14 Step 24 If the desktops are out of alignment from the frame you may need to loosen the grub screws in the framework to adjust the frame to the collect length. Step 25 Finally attach the desktop controller to the underside of the desktop using the wood screws provided.
- Page 15 Step 26 Your desk is now ready to be connected to the mains outlet. Before you proceed with operating your new desk it is recommended that you perform a full reset of the controller to calibrate the height of each leg. This can be done using the following steps;...
- Page 16 Step 27 Upgrading to the Digital control unit Make sure that your height adjustable desk is turned off and unplugged from the mains. Unplug the controller supplied with your height adjustable desk and replace with the digital control unit. Fix this to your top using the wood screws provided. After connecting the digital control unit you will need to perform a reset.
