3. Hardware

The core of the BGM220 Explorer Kit is the BGM220P Wireless Gecko Bluetooth® Module. Refer to section
for placement and layout of the hardware components.

3.1 Block Diagram

An overview of the BGM220 Explorer Kit is illustrated in the figure below.
External connectivity
Breakout Pads
Serial Flash
silabs.com | Building a more connected world.
Debugging
USB Micro-B Debugger
Connector
Radio
2.4 GHz
Antenna
BGM220P
Module
Expandability
Qwiic
Temperature Ambient
Connector
& Humidity Light & UV
Sensor Sensor
Figure 3.1. Kit Block Diagram
J-Link
mikroBUS
Socket
Hall Effect
Sensor
UG465: BGM220 Explorer Kit User's Guide
Hardware
1.4 Kit Hardware Layout
Button and LED
User Button
& LED
