7.2 User Operating Controls

Button
1. OPERATE
2. CODING LED (Red)
3. LIGHT CODE (White)
4. DOOR CODE (Blue)
5. OPEN LED (Green)
6. DOOR STATUS LED (Yellow)
7. CLOSE LED (Red)
01
02
03
04

7.3. Door Status Indicators

Door Status Indicators
Open
Close
Opening
Closing
Door travel stopped
Door obstructed when opening
Door obstructed when closing
Opener overloaded
Door in open position with
Auto-Close mode selected
Mains power interrupted
Function
Opens/stops/closes the door
Flashes when a code is being stored or when the transmitter button is pressed
Is used for storing or erasing the transmitter button (code) you wish to use to switch the courtesy light on
the opener on or off.
Is used for storing or erasing transmitter buttons for door operation
Illuminates and flashes as the door opens and remains on when the open limit position has been reached.
Illuminates when Service is due.
Illuminates and flashes as the door opens closes, and remains on when the close limit position has been
reached.
OPEN LED (green)
On
Flashing
Flashing
Flashing
Alternating flashes
One second flashes
Rapid flashes
05
06
07
CLOSE LED (red)
On
Flashing
Flashing
Beeps while door is moving
Flashing Beeps while door is moving
Alternating flashes
Dominator EasyRoller Instruction Manual
Diamond PD Power Drive : Instruction Manual
© Copyright 2018
Beeper
