6.1. Door Preparation

6.1.1 Prepare the Door:
a. Clean the guides if there is any oil or wax present using a suitable white spirit. The only lubricant suitable for use on door guides is silicon spray.
DO NOT use WD-40, RP-7, petroleum grease, or similar.
b. Remove the locking bars or disable the lock.
c. Install the locking bar covers
operates. (Fig 6.1)
d. Affix the supplied warning labels where they are clearly visible on the inside of the door.

6.2. Fit the Weight Bar

6.2.1 If the door has a handle a weight bar must be fitted to ensure the door doesn't balloon during operation:
a. Remove the door handle
b. Fit the weight bar 6
M4 Nilock Hex nut 7
6.2.2 If the door does not have a handle:
a. Locate the centre of the door at the bottom rail.
b. Place the weight bar at this point and mark the two positions where the fasteners will go
c. Drill the two 4.5mm holes in the door and fit the weight bar
8 and the two (2) M4 Nilock Hex nut
d. Check that the door is still balanced and smooth. If not, then the door may require servicing.
9
WITH HANDLE
10
Dominator EasyRoller Instruction Manual
4
if there are locking bar holes in the guides. This ensures fingers cannot be placed in the holes while the door
4
and refit the handle using the two (2) 8-36 x 2" Pan Head Screws
. (Fig 6.2)
7 .
6
7
8
Fig. 6.1.1
9 and the two (2) Flat Washer
6
using the two (2) 8-36 x 2" Pan Head Screws
9
WITHOUT HANDLE
8 and the two (2)
9
and the two (2) Flat Washer
7
6
8
Fig. 6.2.1
