6.8 Testing & Setting Safety Obstruction Force

6.8.1 Testing the Close Cycle

T E S T I N G T H E C L O S E C Y C L E
S T E P O N E
when the door is closed
Press to open door halfway
S T E P T H R E E
Press to
close
I F T H E D O O R D O E S
Che ck th at th e close li mi t p os i ti on i s w here the doo r
tou ch e s th e grou nd. I f th e do or STO PS b ut do es no t
reve rse , de creas e the force pre s su re .
IMPORTANT WARNING! If the door is closing and is
unable to re-open when obstructed, discontinue use. Do
not use a door with faulty obstruction sensing. Repair
fault and re-test before using.
AVERTISSEMENT IMPORTANT! Si la porte est en train
de se refermer et ne peut pas être rouverte, arrêtez de
l'utiliser. N'utilisez pas une porte dont les détecteurs
d'obstacles sont défectueux. Réparez-les et refaites un
essai.
16
Dominator EasyRoller Instruction Manual
S T E P T W O
Press to
stop
Place a piece of 2" x 4"
timber laid at in centre
of opening
S T E P T W O
When door contacts
object, the door must
STOP and REVERSE!
N O T P R O P E R LY R E V E R S E :
CAUTION: Take care when testing the safety
obstruction force. Excessive force may cause serious
personal injury and/or property damage can result
from failure to follow this warning.
ATTENTION: Testez la résistance aux obstacles avec
précaution. Une force excessive présente un risque
de blessure corporelle grave et/ou d'endommager le
matériel si vous ne respectez pas cet avertissement.

6.8.2 Testing the Open Cycle

T E S T I N G T H E O P E N C Y C L E
S T E P O N E
when the door is closed
Press to open door
I F T H E D O O R D O E S N O T S T O P : Th e F orc e p re s su re
m ay b e e x ce s s i v e an d n e e d a d ju s t i n g . Fol l ow st e p s t o
d e cre as e f o rce p res s u re .
S T E P T W O
When the door reaches
halfway, grab the bottom
rail rmly. Door should STOP!
