Tuuci OCEAN MASTER MEGA MAX CENTER POST Installation Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
I N S T A L L A T I O N
I N S T R U C T I O N S
OCEAN MASTER MEGA MAX CENTER POST
HARDWARE AND PARTS INCLUDED (IMAGES ARE NOT 1:1 SCALE)
DESCRIPTION
QTY
a
Crank Handle
b
Base Stem
c
Beauty Cover
d
1/2" Allen Wrench
e
5/16" Allen Wrench
f
Finial
Screw
g
13
#10 x 7/8"
INCLUDED ON MODEL WITH LIGHT
Allen Wrench
n
2.5mm
Ambia LED Light
o
+ Touch Switch
IMPORTANT: THE ANCHOR MUST BE INSTALLED BEFORE MOUNTING THE PARASOL.
TO PROTECT YOU AND YOUR PRODUCT, PLEASE READ THE INSTALLATION INSTRUCTIONS.
1009234
PART IMAGE
1
1
1
1
1
1
1
1
DESCRIPTION
Screw
h
1/2-13" x 1-1/2" FHCS
Screw
i
1/2-13" x 2-1/4" FHCS
j
Washer, 1/2"
k
Nut, 1/2-13"
l
Lubricant
m
Canopy
INCLUDED ON MODEL WITH HEATER
p
Solamagic Heater
q
Beauty Cover
1
QTY
PART IMAGE
5
5
5
5
1
1
see WT
2
TUUCI.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the OCEAN MASTER MEGA MAX CENTER POST and is the answer not in the manual?

Questions and answers

Related Manuals for Tuuci OCEAN MASTER MEGA MAX CENTER POST

Summary of Contents for Tuuci OCEAN MASTER MEGA MAX CENTER POST

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST HARDWARE AND PARTS INCLUDED (IMAGES ARE NOT 1:1 SCALE) DESCRIPTION...
  • Page 2 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 1 Ensure the Stainless Steel Hinged Surface Anchor has...
  • Page 3 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 4 Remove the hardware box and Stainless Steel Security Stem (the stem is inside the parasol mast).
  • Page 4 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 6 Roll the cart to the Stainless Steel Security Stem with the bottom of the mast facing the stem.
  • Page 5 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 9 Requires 4 to 6 people (depending on size).
  • Page 6 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 11: TO RAISE THE PARASOL, SELECT THE APPROPRIATE OPTION.
  • Page 7 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 13 Remove the rope, white straps, and plastic cover.
  • Page 8 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST Step 15 Gently separate each rib from the mast before operating the crank. Install EasyDrive® Crank Lift and turn the crank clock- wise to open the canopy, remove any remaining packaging material.
  • Page 9 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST IF APPLICABLE: AMBIA LED LIGHT INSTALLATION countersunk hole light light...
  • Page 10 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST IF APPLICABLE: TURNING THE AMBIA LED LIGHT ON WITH TOUCH SWITCH...
  • Page 11 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST IF APPLICABLE: HEATER INSTALLATION rib brackets Step 1 Step 2 Mount heaters to rib bracket using Connect heater cables.

  • Page 12: Canopy Installation

    I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST CANOPY INSTALLATION If applicable: install heaters and light before installing the canopy.

  • Page 13: Top View

    I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST CANOPY INSTALLATION CON'T Step 4 For rectangular parasols, unfold them towards the longer side of the frame.
  • Page 14 I N S T A L L A T I O N I N S T R U C T I O N S OCEAN MASTER MEGA MAX CENTER POST CANOPY INSTALLATION CON'T Step 6 Step 7 Remove the ladder, close the parasol, and pull Use screws #10x7/8"...
  • Page 15 IF APPLICABLE: TURNING ON HEATERS Step 1 Plug your parasol into a 220V receptacle. When the parasol has been correctly plugged into the power source, the Tuuci logo on the user control panel will be backlit in white. Step 2 Press the power button to turn on the parasol.
  • Page 16 Control panel indicator when the parasol is not level (tipped or tilted on an angle): The power button will flash in yellow when the parasol is not level. All functions are inactive. The Tuuci logo is not back lit. When the parasol is level and no longer tipped or tilted, it will return to a powered-down state with the Tuuci logo backlit in white and all other functions off.
