Gps Shielding Conductive Gasket - Sony Ericsson Xperia Mini Pro Working Instructions

Replacement

4.22 GPS Shielding Conductive Gasket

Follow the 3.1 – 3.3 Disassembly instructions.
Prepare the new GPS Shielding Conductive Gasket.
Follow the 5.5 – 5.7 Reassembly instructions.
REMOVAL
Detach and remove it using a Flex Film Assy Tool.
Scrap the GPS Shielding Conductive Gasket! It cannot
be reused!
INSTALLATION
Attach a new GPS Shielding Conductive Gasket in the
guiding line area as shown.
Press to secure its attachment.
