Reassembly
Press the opposite side to snap the other three hooks as
shown.
Press the top side to snap the two hooks as shown.
Press the bottom side to snap the two hooks as shown.
Apply 10 Ncm torque when tightening the two Screws
M1.4X2.0 with Bits (JCIS No 0).
Take new screws!
