Table X-1 Function definition of the back terminal of the controller
No.
9
10
11
15
16
1～8,12,13,14
11.4 Installation Dimensions
Page 31
SH-HC30 Height Controller System Manual
Property
Power supply
Power supply 24V ground, height controller power supply
Input
RS232 communication receiving terminal
Input
RS232 communication receiving terminal
Power supply
Power supply 24V positive, height controller power supply
Power supply
Power supply 24V ground, height controller power supply
No functional definition
96X48mm
96mm
Description
12
68
