SH-HC30 Height Controller System Manual
The electrical installation diagram of height controller when the arc
voltage detection and the capacitive detection are used together.
Plasma Power Supply
Arc voltage signal
15-pin
High-frequen
分压板 9 芯接头
back of numerical control
The
Height controller
Capacitive detecting ring
25pin
Page 13
