Black 15" Versatile Desktop Shelf Riser
Instruction Manual
SKU: DESK-SHELF15B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-shelf15b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo DESK-SHELF15B
Summary of Contents for Vivo DESK-SHELF15B
- Page 1 Black 15" Versatile Desktop Shelf Riser Instruction Manual SKU: DESK-SHELF15B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-shelf15b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Assembly Options
ASSEMBLY OPTIONS: Desk Shelf Riser can be assembled in one of three ways. Choose an option below and follow the provided instructions for assembly. Inward Facing | pg 4 Shelf clamps to desktop DESKTOP and sits above the clamps Outward Facing | pg 5 Shelf clamps to desktop and DESKTOP extends away from clamps... - Page 4 ASSEMBLY OPTION A: Inward Facing STEP 1 Secure L Brackets (B) to Shelf (A) using M6x25mm Screws (S-B), M6 Washers (S-E), and 4mm Allen Wrench (T-A). STEP 2 Insert Clamp Screw (D) through Short Bracket (C), then connect Clamp Plate (F) using M4 Washers (S-A), M3x8mm Screws (S-D), and a Phillips Screwdriver.
- Page 5 ASSEMBLY OPTION B: Outward Facing STEP 1 Secure L Brackets (B) to Shelf (A) using M6x25mm Screws (S-B), M6 Washers (S-E), and 4mm Allen Wrench (T-A). STEP 2 Insert Clamp Screw (D) through Short Bracket (C), then connect Clamp Plate (F) using M4 Washers (S-A), M3x8mm Screws (S-D), and a Phillips Screwdriver.
- Page 6 ASSEMBLY OPTION C: Freestanding STEP 1 Secure Short Brackets (C) to Shelf (A) using M6x25mm Screws (S-B), M6 Washers (S-E), and 4mm Allen Wrench (T-A). STEP 2 Apply Foot Pads (H) to the long underside of L Brackets (B). Secure L Brackets (B) to Short Brackets (C) using M6x20mm Screws (S-C) and 4mm Allen Wrench (T-A).
- Page 7 THIS PAGE INTENTIONALLY LEFT BLANK...
