Black Electric Premium Single Column Desk Leg
Instruction Manual
SKU: DESK-V101EC
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v101ec
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo DESK-V101EC
Summary of Contents for Vivo DESK-V101EC
- Page 1 Black Electric Premium Single Column Desk Leg Instruction Manual SKU: DESK-V101EC Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v101ec GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Electrical Safety Instructions
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Tools Needed
TOOLS NEEDED Phillips Screwdriver DO NOT EXCEED WEIGHT CAPACITY. 110lbs Failure to do so may result in serious injury. Level (49.90kg) ASSEMBLY STEPS STEP 1 Press anti-vibration pads (S-E) into top of support bar (A). Insert lifting column (B) into underside of support bar as shown, making sure the motor cable is placed through the slot in front. - Page 4 STEP 3 Screw the feet (D) into the base. STEP 4 Place the desktop upside down on a flat surface and position the leg/base assembly upside down on the desktop. Secure the assembly using x6 Phillips head screws with spacers (S-C), and tighten with a Phillips screwdriver.
- Page 5 STEP 6 Route motor cables through slots and connect to the control panel (H). STEP 7 Place the adapter (E) into the support bar as shown. Connect the control panel cable to the adapter. STEP 8 Install the power cable (G) to the socket in the adapter, then route through the cable hole in the base.
- Page 6 STEP 9 Attach the cable management clips (F) to the lifting column to hold the power cable in place. Ensure the power cable has enough slack between the desktop and the clips for proper movement of the desk. Peel the backing from the cable clip (S-D) and stick to underside of desktop between the control panel and adapter to manage cables.
- Page 7 CAUTION! Do not exceed desk weight limit. Keep area of vertical motion free of obstacles. Keep weight on desk balanced for Leave enough slack in cables to correct operation and longer life of allow for full range of vertical components. motion.
