Black Clamp-on 60" Cable Management Desk Organizer
Instruction Manual
SKU: DESK-SKIRT-60P
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-skirt-60p
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo DESK-SKIRT-60P
Summary of Contents for Vivo DESK-SKIRT-60P
- Page 1 Black Clamp-on 60” Cable Management Desk Organizer Instruction Manual SKU: DESK-SKIRT-60P Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-skirt-60p GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 STEP 2 Open the flap and straps of Panel (A) and insert the frame, making sure the frame is fully inserted and the material is tightly stretched around it. STEP 3 Fasten the straps on Panel (A) to secure the frame. STEP 4 Place Mounting Clips (E) in the center of each exposed portion of Upper/Lower Bars (F).
- Page 4 STEP 5 For thinner desktops (<1.5” (40mm)), adjust Clamp (D) by disassembling, flipping the bottom bracket, and reassembling using a Phillips screwdriver. STEP 6 Secure Mounting Clips (E) to Clamp (D) in one of four mounting locations using Screws (S-A).
- Page 5 STEP 7 Mount the assembled panel to the desktop and tighten Clamps (D) to secure the assembly in place. STEP 8 Route and organize the cables and secure them using the flap on the panel (A).
- Page 6 STEP 4 (Optional) Screw Mounting Place the Mounting Clips (E) in the center of each exposed portion of Upper/Lower Bars (F). NOTE: Make sure the wire management flap on Panel (A) is facing the inside of the desktop. STEP 5 (Optional) Screw Mounting Center the assembled panel under the desktop.
- Page 7 STEP 6 (Optional) Screw Mounting Mark the locations of Mounting Clips (E) using a pencil. Drill pilot holes using a 1/8” (3mm) bit and mount the assembled panel to the underside of the desk using 3/4” Screws (M-A) as shown. NOTE: Desktop must be at least 1”...
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
