Vivo DESK-SHELF22B Instruction Manual

Black 22" versatile desktop shelf riser

Hide thumbs Also See for DESK-SHELF22B:

Download this manual

Black 22" Versatile Desktop Shelf Riser

Instruction Manual

SKU: DESK-SHELF22B

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

https://vivo-us.com/products/desk-shelf15b

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

help@vivo-us.com

www.vivo-us.com

Chat live with an agent!

309-278-5303

Need help?

Do you have a question about the DESK-SHELF22B and is the answer not in the manual?

Page 1 Black 22" Versatile Desktop Shelf Riser Instruction Manual SKU: DESK-SHELF22B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-shelf15b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
Page 2: Assembly Options
WARNING! ASSEMBLY OPTIONS: If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or Desk Shelf Riser can be assembled in one of three ways. Choose an option below and follow the defective parts.
Page 3 ASSEMBLY OPTION A: Inward Facing ASSEMBLY OPTION B: Outward Facing STEP 1 STEP 1 Secure L Brackets (B) to Shelf (A) using M6x25mm Screws (S-B), M6 Washers (S-E), and 4mm Allen Secure L Brackets (B) to Shelf (A) using M6x25mm Screws (S-B), M6 Washers (S-E), and 4mm Allen Wrench (T-A).
Page 4 ASSEMBLY OPTION C: Freestanding STEP 1 Secure Short Brackets (C) to Shelf (A) using M6x25mm Screws (S-B), M6 Washers (S-E), and 4mm Allen Wrench (T-A). STEP 2 Apply Foot Pads (H) to the long underside of L Brackets (B). Secure L Brackets (B) to Short Brackets (C) using M6x20mm Screws (S-C) and 4mm Allen Wrench (T-A).
