Clamp-on Under Desk Mesh Cable Management
Instruction Manual
SKU: DESK-AC36MH
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-ac36mh
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo DESK-AC36MH
Summary of Contents for Vivo DESK-AC36MH
- Page 1 Clamp-on Under Desk Mesh Cable Management Instruction Manual SKU: DESK-AC36MH Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-ac36mh GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 STEP 2 Feed assembled Support Bars (A) through middle holes of Mesh Panel (C), then slide them to the right. Insert Support Bars (A) into the middle holes of Mesh Panel (C), then slide them to the left and attach to existing left side Connectors (B).
- Page 4 STEP 3 Loosen Clamp (E) hand crank to lower Plastic Screwhead (E1). Slide Hook (D) through back of Clamp (E), with teeth facing up and keyhole in front. Aligh Hook (D) keyhole over Plastic Screwhead (E1) and slide all the way back so that the Hook is secure in place.
- Page 5 STEP 4 Place Clamps (E) onto desktop and being to tighten. Leave a small gap of space between Hooks (D) and the desktop to ensure the mesh assembly can be properly secured.
- Page 6 STEP 5 Place mesh assembly onto front teeth of Hooks (D) and tigten Clamps (E) to secure.
- Page 7 STEP 6 Pull lower portion of mesh assembly back and secure into back slots of Hooks (D). Use Velcro Cable Ties (F) to secure cable bundles and place onto mesh assembly.
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
