- Page 1 Clamp-on Desk Stabilizer SKU: DESK-STB01B/W Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/desk-stb01b...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x1) B (x1) Outer Stabilizer Bar Inner Stabilizer Bar Included Hardware & Tools S-A (x2) S-B (x2) T-A (x1) M6x12mm Screw M6 Nut 5mm Allen Wrench Tools Needed: Phillips 10mm Screwdriver Wrench... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Insert Inner Stabilizer Bar (B) into the Outer Stabiliter Bar (A). STEP 2 Partially loosen the four screws on each side of the stabilizer using 5mm Allen Wrench (T-A) to allow the clamps to slide freely. Clamp... - Page 5 STEP 3 **Please Read** Stabilizer can be used on Height Adjustable Desks and Non-Height Adjustable Desks. Follow the instructions that match your desk style. **Non-Height Adjustable Desks** Proceed to the next page for Height Adjustable Desks Tighten the Clamps onto the desk legs. Clamp Proceed to STEP 4 on Page 7...
- Page 6 **Height Adjustable Desks** See previous page for Non-Height Adjustable Desks Determine the leg style of your desk. Leg Type A: Leg Type B: Outer Casing on Bottom Outer Casing on Top Outer Casing Outer Casing Clamp the stabilizer in the location according to your desk’s leg type. See next page for Leg Type B.
- Page 7 Height Adjustable Desks - Cont’d Leg Type B: Lower the desk to its lowest setting, then place and tighten Clamps near the bottom of the legs. ** Do Not Over-Tighten** Over-tightening the clamps may restrict movement of a height-adjustable desk, placing excess strain on the mechanism.
- Page 8 LAST UPDATED: 08/21/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
