Cold Jet PR350H Pre-Installation page 71

POS. DESCRIPTION
1
2 End Cap
3
4
5 Joint Gasket
6 Stem
7 Stem Seal
8 Stem Seal
10 Belleville Washer
11 Lock Saddle
12 Stem Nut
13 Handle
14 Handle Sleeve
15 STOP
16
17
18 Locking Device
19 Anti-Static Device
Body
Ball
Seat
Bolt
Nut
PR120H
MECHANICAL MAINTENANCE
MATERIAL TYPE
Stainless steel - AISI 316
Stainless steel - AISI 316L
Stainless steel - AISI 316
PTFE with 25% carbon composit
PTFE
Stainless steel - AISI 316
PTFE with 25% carbon composit
75% PTFE, 20% glas fiber, 5%
graphite
Stainless Steel - AISI 301
Stainless Steel - AISI 304
Stainless Steel - AISI 304
Stainless Steel - AISI 304
VINYL
Stainless Steel - AISI 304
Stainless Steel - AISI 304
Stainless Steel - AISI 304
Stainless Steel - AISI 304
Stainless Steel - AISI 304
Version: 5
Page: 21 of 24
Date: 2022.12.13
