Cold Jet E-CO2 150 Operator's Manual

Dry ice blasting + abrasive
Hide thumbs

Advertisement

Quick Links

Dry Ice Blasting + Abrasive E-CO
150
2
Operator Manual
Original Instructions [English]
January 2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the E-CO2 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cold Jet E-CO2 150

Summary of Contents for Cold Jet E-CO2 150

  • Page 1 Dry Ice Blasting + Abrasive E-CO Operator Manual Original Instructions [English] January 2020...
  • Page 2 Cold Jet and the client and remains the exclusive property of Cold Jet. If you find any problems in the documentation, please report them to us in writing. Cold Jet does not warrant that this document is error-free.

  • Page 3: Table Of Contents

    Contents Introduction ................................1 Safety ..................................3 E-CO 150 Description ............................10 Operations ................................13 Maintenance ..............................31 Warranty ................................32 Technical Schematics............................33 Contact Information ............................42...

  • Page 5: Introduction

    This manual illustrates the safety, operation, and maintenance features of the Cold Jet E-CO 150. The design contained in this manual was originated by and is the exclusive property of Cold Jet, LLC. It is not to be used in any way detrimental to the interests of Cold Jet, LLC.
  • Page 6 Item Part No. Description 2A0354 E-CO 150, Pneumatic (Pair with Aero C100) Kits 2A0356 E-CO 150, Electric (Pair with Aero PLT 60) 2A0355 E-CO 150, Electric (Pair with Aero 80FP) 4E0291 #7 - 7/16 in x 8 1/2 in (1.1 cm x 21.6 cm) 4E0290 #6 - 3/8 in x 7 3/8 in (.9 cm x 18.7 cm) Nozzles...

  • Page 7: Safety

    Safety General Safety Guidelines This machine does not pose a risk to the operator when the instructions in this manual are followed carefully. However, certain precautions must be followed during its use. To understand all the necessary precautions, the machine operator must read the entire manual before operating or performing maintenance on the E-CO 150.
  • Page 8 Safety Labels The symbols used on the machine were developed by the International Organization for Standardization (ISO) and are defined below. These symbols may include yellow warnings triangles, blue mandatory action circles or red prohibited action circles. Symbol Definition General Warning Cold Temperature Warning Pressurized Material Ejection Hazards Electrostatic Discharge Warning...
  • Page 9 Symbol Definition Hearing Hazard Pressurized Hose Wear Protective Gloves Wear Hearing Protection Wear Eye Protection Read Operator and Maintenance Manual Along with MSDS Information Wear Respirator as Required Wear Full Face Shield Do Not Operate Without Safeguard Grate/Guard in Place No Foreign Objects Allowed Inside Machine is in Use Protective Earth/Ground...
  • Page 10 Cautions and Warnings Please review the following cautions and warnings before operating or performing maintenance on the machine. WARNING All persons who will be operating or will be in the vicinity of the Abrasive Blaster during its operation must receive proper training on how to safely operate the equipment and be informed of the potential hazards involved.
  • Page 11 Use only Genuine Cold Jet replacement parts when performing maintenance on the Abrasive Blaster. Do not modify the equipment for any reason. Use of modified or non-Cold Jet parts can cause an unsafe situation and will void your warranty. NEVER use malfunctioning or damaged equipment. Before each use, inspect WARNING the Abrasive Blaster for proper function.
  • Page 12 WARNING To ensure machine safety, use only original spare parts from Cold Jet or approved by Cold Jet. WARNING The control air hose contains electrical connections. Do not immerse in water. WARNING Do not use the machine if a supply cord or important parts of the machine are damaged, (e.g.
  • Page 13 E-CO 150 Data Dimensions 24 in x 21 in x 39 in (61 cm x 53 cm x 99 cm) Dry Weight 135 lb (61 kg) Pot Capacity 150 lb (68 kg) Blast Pressure Range 50 to 150 psi (3.5 to 10.3 bar) Supply Pressure Range 100 to 150 psi (6.9 to 10.3 bar) Nozzle Air Consumption Range...

  • Page 14: E-Co 150 Description

    E-CO 150 Description E-CO will be supplied as follows: Abrasive pot & fittings Blast hose 2 bags 50 lb (22.7 kg) medium grade abrasive media Choice of one abrasive blast nozzle Exhaust Air Valve BACK FRONT and Muffler Air Supply to Tank Valve Abrasive/No Abrasive Selector Switch...
  • Page 15 E-CO 150 Recommended Components Figure 2: E-CO 150 /Aero2 PLT 60 Overview Figure 3: E-CO 150 Operator with proper PPE...
  • Page 16 E-CO Nozzles Nozzle Nozzle Part No Nozzle Specifications #7 - 7/16 in x 8 1/2 in (1.1 cm x 21.6 cm) 4E0291 255 cfm (7.2 m³/m) @100 psi #6 - 3/8 in x 7 3/8 in (.9 cm x 18.7 cm) 4E0290 200 cfm (5.7 m³/m) @100 psi #5 - 5/16 in x 6 1/4 in (.8 cm x 15.9 cm)

  • Page 17: Operations

    150 during shipment or packing. Refer to the packing slip for a list of the components shipped with the E-CO 150. Contact Cold Jet if any damage has occurred to the shipping container or the E-CO 150 (see “Contact Information” on page 42).
  • Page 18 Do not use the machine if any important parts of the machine are damaged, (e.g. safety devices, high pressure hoses, applicator). These instructions will apply to all three models of Cold Jet blasters. The illustrations may or may not correspond to the dry ice blasting machine you are using.
  • Page 19 Compressed Air Supply It is important for proper operation of both, the dry ice blaster and the abrasive blaster, that the incoming air is connected properly. The abrasive media system has a pressure rating of 150 psi (10.3 bar). It is therefore necessary that the blast pressure of the dry ice blaster be set no higher than 135 psi (9.3 bar).
  • Page 20 The Cold Jet After Cooler is required to reduce the discharge air temperature 180° F (82° C) to within 15°F (-9°C) of ambient air temperature. Visit coldjet.com to learn more about purchasing a Cold Jet After Cooler.
  • Page 21 Connecting the E-CO 150 to the Dry Ice Blaster Before connecting any hoses to the E-CO 150, ensure that the inlet valve is closed and the compressed air supply is off. ALWAYS use safety devices like slips and whip checks (safety cables) at hose WARNING connections.
  • Page 22 PLT 60 connections: When connecting the air supply hose to the blaster, always run the hose through the choker of the whip check in case of accidental disconnect. Figure 5: Whip Check Aero PLT 60 Connections: Figure 6: Aero PLT 60 Connections...
  • Page 23 Aero C100 Connections: Figure 7: Aero C100 Connections Aero 80FP Connections: Figure 8: Aero 80FP Connections...
  • Page 24 Attaching the Blast Hose to the E-CO There are three connections to be made when attaching the blast hose. The large blast hose and two small signal hoses with quick connect fittings. The large hose has a twist claw type fitting. Line up the ‘feet’...
  • Page 25 Safety Pin Figure 11: Attaching the Blast Hose Dry Ice Only Abrasive Dry Ice Figure 12: Signal Hose Connections Connect the small signal hoses into the control side of the Abrasive Blaster. There is only one way they will connect.
  • Page 26 Figure 13: Nozzle Assembly When installing the nozzle, be sure the nozzle seal is small side down/toward the blast hose as illustrated in figure 13 and not toward the nozzle or the nozzle connection may leak around the seal. In order to activate the trigger to the nozzle, the safety button must be depressed. Trigger Safety Button Figure 14: Trigger and Safety Button...
  • Page 27 Only personnel thoroughly trained in abrasive blasting should operate the E-CO 150. This manual only provides the basic information on how to safely operate the features of the Cold Jet series E-CO 150. This manual only covers the E-CO 150 of the Dry Ice Blasting + Abrasive System. For any information on the dry ice blaster refer to that machines manual.
  • Page 28 Figure 15: Aero PLT 60 Trigger Connector Button Blasting Dry Ice Only NEVER point the blast nozzle at yourself, other people, or equipment that is WARNING not intended to be blasted. NEVER use the E-CO WARNING 150 without a nozzle securely installed in the blast hose nozzle holder.
  • Page 29 Figure 16: E-CO 150 Selector Plate When the switch is in the DRY ICE ONLY position, only the Dry Ice Blaster is activated when the trigger is engaged and no abrasive media will be added to the blast stream. Engage the trigger handle. The safety button on the side must be depressed and the handle compressed.
  • Page 30 WARNING If operating in DRY ICE ONLY mode it can blast up to 250 psi (17.2 bar) max. If switched to the ABRASIVE & DRY ICE mode while the blast pressure is set above 150 psi (10.3 bar), this will cause one or two pressure relief valves to activate.
  • Page 31 Once all pressure leaves the tank, the tank seal ball will visibly drop allowing the operator to load abrasive media into the tank for blasting. Use the chart below to add the correct portions for blasting and to set the metering valve. Once abrasive media is added to the tank, close the Blowdown valve and open the Air supply to the tank.
  • Page 32 Setting the Abrasive Flow The Abrasive Metering Valve (figure 20) can be set to deliver between 1.2-10 lb/min (.5-4.5 kg/min) of abrasive. The knob can only be turned when you are not blasting or in the ice only mode. It usually takes about 6 complete turns (counter-clockwise) of the knob from the completely closed position to start the abrasive flowing.
  • Page 33 Nozzle # Nozzle Air, Power 50 psi 60 psi 70 psi 80 psi 90 psi 100 psi 125 psi 140 psi Orifice & Abrasive Re- 3.45 bar 4.14 bar 4.83 bar 5.52 bar 6.21 bar 6.89 bar 8.62 bar 9.65 bar Size quirements cu ft/min...
  • Page 34 Shutting down the E-CO NEVER disconnect any compressed air supply hose without first performing WARNING the “DISCONNECT AIR SUPPLY HOSE” procedure described in this manual. Failure to do so can cause the hose to blow off unexpectedly and cause possible harm. 1.

  • Page 35: Maintenance

    Maintenance WARNING Prior to any maintenance or inspection procedures to the E-CO 150, ensure that the air supply and Dry Ice Blaster are powered down and the power source is disconnected. Ensure that the air supply is closed, bled off and the air supply hose is disconnected from the system.

  • Page 36: Warranty

    Warranty Cold Jet® (“CJ”) warrants its products (“Equipment”) provided under this Agreement to be free from defects in materials and workmanship for a period of 12 months (90 days on used equipment), under normal use, maintenance and service as stipulated in the Operator’s Manual, Commissioning, and Operator Training. At the discretion of CJ, failure to complete Installation, Commissioning, and Operator Training shall result in forfeit of warranty rights.

  • Page 37: Technical Schematics

    Technical Schematics Pneumatic Schematics .......................... 34-39...
  • Page 39 C100 E-CO 150 Schematic...
  • Page 41 Aero 80FP E-CO 150 Schematic...
  • Page 43 PLT 60 E-CO 150 Schematic...
  • Page 45 NOTES ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________...

  • Page 46: Contact Information
