Ultrasonic sensor
Table of Contents

Advertisement

Ultrasonic sensor

Technical Data

Indicators/operating means
LED green
LED yellow
LED red
Electrical specifications
Operating voltage
No-load supply current
Interface
Interface type
Input/Output
Input/output type
0 Level
1 Level
Input impedance
Output rated operating current
Pulse length
Pulse interval
Synchronization frequency
Common mode operation
Multiplex operation
Input
Input type
Level (switch point 1)
Level (switch point 2)
Input impedance
Pulse length
Output
Output type
Rated operating current
Voltage drop
Repeat accuracy
Switching frequency
Range hysteresis
Temperature influence
Compliance with standards and directives
Standard conformity
Standards
Approvals and certificates
UL approval
CCC approval
Ambient conditions
Ambient temperature
Storage temperature
Mechanical specifications
Connection type
Degree of protection
Material
Housing
Transducer
Mass
Factory settings
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group
USA: +1 330 486 0001
www.pepperl-fuchs.com
fa-info@us.pepperl-fuchs.com
Operating display
switching state
error
U
10 ... 30 V DC , ripple 10 %
B
I
≤ 50 mA
0
Serial interface (programming adapter required)
9600 BPS, no parity, 8 data bits, 1 stop bit
1 synchronization connection, bidirectional
0 ... 1 V
4 V ... U
B
> 12 kΩ
< 12 mA
0.5 ... 300 ms (level 1)
≥ 33 ms (level 0)
≤ 30 Hz
≤ 33 Hz / n , n = number of sensors , n ≤ 10
(factory setting: n = 5 )
1 program input
0 ... 1 V
4 V ... U
B
> 10 kΩ
2 ... 10 s
1 switching output E5, PNP NO/NC, programmable
I
200 mA , short-circuit/overload protected
e
U
≤ 2 V
d
≤ 0.1 % of full-scale value
f
≤ 5 Hz
H
programmable , preset to 1 mm
< 1.5 % of full-scale value
EN IEC 60947-5-2:2020
IEC 60947-5-2:2019
cULus Listed, Class 2 Power Source
CCC approval / marking not required for products rated ≤36 V
-40 ... 70 °C (-40 ... 158 °F)
-40 ... 85 °C (-40 ... 185 °F)
Connector plug M12 x 1 , 5-pin
IP67
PA-GF35
epoxy resin/hollow glass sphere mixture; polyurethane foam
115 g
Germany: +49 621 776 1111
Singapore: +65 6779 9091
fa-info@de.pepperl-fuchs.com
fa-info@sg.pepperl-fuchs.com
UC2000-L2-E5-V15-Y291515
SS
2
