Ultrasonic sensor

Dimensions
LED ye

Electrical Connection

Pinout
Wire colors in accordance with EN 60947-5-2
1
2
3
4
5
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
2
Pepperl+Fuchs Group
www.pepperl-fuchs.com
LED gn LED ye
LED gn
67
40
5.5
46
60
1
L+
2
Program input
5
Synchronization
4
Switch output
3
L-
1
5
2 4
3
BN (brown)
WH (white)
BU (blue)
BK (black)
GY (gray)
USA: +1 330 486 0001 Germany: +49 621 776 4411
fa-info@us.pepperl-fuchs.com fa-info@de.pepperl-fuchs.com
ø 5.5
Singapore: +65 6779 9091
fa-info@sg.pepperl-fuchs.com
UC2000-L2-E5-V15
