Ultrasonic Sensor; Additional Information - Pepperl+Fuchs UC6000-30GM-2EP-IO-V15 Quick Start Manual

Ultrasonic sensor

Standards
Approvals and certificates
UL approval
CSA approval
CCC approval
Dimensions
36
Electrical Connection
Pinout
Wire colors in accordance with EN 60947-5-2
1
2
3
4
5
2
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group
www.pepperl-fuchs.com
EN 60947-5-2:2007 + A1:2012
IEC 60947-5-2:2007 + A1:2012
cULus Listed, General Purpose
cCSAus Listed, General Purpose
CCC approval / marking not required for products rated ≤36 V
ø73
LED
ø7
M12
1
L+
5
Sync.
4
C/Q
2
Switch output 2
3
L-
1
5
4
2
3
BN (brown)
WH (white)
BU (blue)
BK (black)
GY (gray)
USA: +1 330 486 0001 Germany: +49 621 776 4411
fa-info@us.pepperl-fuchs.com fa-info@de.pepperl-fuchs.com
UC6000-30GM-2EP-IO-V15

Additional Information

Switching output operating modes
1. Switching point mode
Near
switching
point
NO contact
NC contact
2. Window mode
NO contact
NC contact
3. Hysteresis mode
NO contact
NC contact
4. Retroreflective sensor mode
NO contact
NC contact
Singapore: +65 6779 9091
fa-info@sg.pepperl-fuchs.com
Far
switching
point
