DEMO MANUAL DC2733A

PERFORMANCE SUMMARY

PARAMETER
IN1 and OUT1 Operating Voltage Range
IN2 and OUT2 Operating Voltage Range
(INn - OUTn)
INn Forward Current
(2)
INn Reverse Current
CHn Switch Resistance while On
CHn Switch Resistance while Off
Circuit Breaker Response Time (1x OC)
IMON Output Current Accuracy
Circuit Breaker Threshold Accuracy
(1) IN2 may be tied to GND if unused.
(2) Reverse current is only permitted when the channel is on. An internal diode from OUTn to INn will forward bias if OUTn voltage is above INn.
(3) IMON does not register reverse current. The circuit breaker will not respond to reverse current.
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
Specifications are at T
CONDITIONS
Referenced to GROUND
(1)
Referenced to GROUND
Channel off.
Reverse voltage not permitted.
Forward current flows from INn to OUTn
Reverse current flows from OUTn to INn
Channel enabled
V > 1.2V
IMON
(3)
I = 1.0A
OUT
1× threshold
= 25°C
A
MIN
6
1.5
0
0
–1.2
300
–3
–2.5
TYP MAX UNITS
65 V
65 V
65 V
1.2 A
0 A
75 150 mΩ
kΩ
60 μs
3 %
2.5 %
Rev. A
