DEMO MANUAL DC2566A

pArts list

ITeM QTY reFereNCe
required Circuit Components
1 2 C1,C2
2 1 C3
3 3 E1-E3
4 2 J1, J2
5 1 J3
6 1 U1
4
pArT DesCrIpTION
CAP ., 18pF, C0G, 50V, 1%, 0402
CAP ., 1µF, X7R, 10V, 10%, 0603
TEST POINT, TURRET, 0.061" MTG. HOLE
CONN., SMA 50Ω EDGE-LAUNCH
CONN., SMA 50Ω EDGE-LAUNCH
I.C. LTC5553IUDB, QFN 12 PIN, 3mm x 2mm
MANUFACTUrer/pArT NUMber
MURATA, GJM1555C1H180FB01
MURATA, GRM188R71A105KA61
MILL-MAX, 2308-2-00-80-00-00-07-0
E. F . JOHNSON, 142-0761-881
E. F . JOHNSON, 142-0701-851
LINEAR TECHNOLOGY, LTC5553IUDB#PBF
dc2566af
