Mounting and connection

1.6 LED display

1.6.1 Overview

The LEDs give you the following information:
ADDI-DATA logo
Power On
Port 0 ACT/Link
Port 1 ACT/Link
www.addi-data.com
Table 1-5: LED display
LED
Lights white
No display
No display
Lights green
No display
or
Lights yellow
Flashes yellow
Status
Lights green
Fur further display
settings, see the
following table.
Display
The system is ready for
operation.
The system is in energy-
saving mode.
ADDI-DATA
®
There is no voltage applied.
Voltage is applied.
The system is ready for
operation.
There is no network
connection.
The Ethernet cable is
connected to Port 0 or 1.
The network connection is
established.
The system is ready for
operation.
20
Meaning
MSX-Exxxx
