Mounting and connection
1.4.2 Trigger and synchro signals
Plug the cable into the connector "Trig/Sync In"
1.4.3 Voltage supply
Plug the cable into the input "24 VDC In"
1.4.4 Sensors or actuators
Information concerning the type of sensor or actuator, the corresponding pin assignment as well as
connection examples can be found in the respective system-specific MSX-E manual.
Fig. 1-11: MSX-Exxxx: Connect sensors or actuators (example)
3 If you want to connect several Ethernet systems, please read Chapter 1.5.
www.addi-data.com
3
(see Fig. 1-10).
1
(see Fig. 1-10).
18
MSX-Exxxx
