Mounting and connection MSX-Exxxx

Fig. 1-2: Type label

Serial
Disposal label
number
Version
Product name
Customisation
Supply voltage
Nominal
Current voltage
consumption
The type label contains, for example, the product name including the specific version name, and the
serial number of the Ethernet system. In case of queries, these details always have to be kept at hand!
For more information on the disposal label, see Chapter 6.2.
Information on cables and other accessories can be found in the accessories list of the MSX-E systems.
