Mounting and connection

1 Mounting and connection

1.1 Commissioning of the Ethernet system (overview)

Discharge any static by touching an earth wire.
Remove the Ethernet system from its protective packaging.
Check the type label on the bottom side of the Ethernet system to know if the system corresponds
to your requested version.
www.addi-data.com

Fig. 1-1: Commissioning (overview)

Risk of injury!
Please follow the safety precautions! An improper handling of the
Ethernet system may cause property damage and injury.
8
MSX-Exxxx
