- Page 1 This manual forms an integral part of the vacuum cleaner. DEPURECO recommends to read carefully this manual and the other attachments supplied. Knowledge of the instructions here contained is indispensable for the safe use and ed. C - 10/11/2016 maintenance of the vacuum cleaner.
-
Page 2: Table Of Contents
General safety rules ……………………………………………………………………. Filter replacement ………………………………………………………………………. Troubleshooting …………………………………………………………………………. Life cycle end ……………………………………………………………………………. Copyright - This document belongs exclusively to DEPURECO - S.r.l. Consequently all rights are reserved. Any form (graphic, computer, etc.), of copy or part is not allowed without Management authorization. -
Page 3: Information Section
INFORMATIVE SECTION Forword Dear Customer Thank you for preferring DEPURECO and congratulate you on choosing a DEPURECO series BULL vacuum cleaner. This manual has been prepared to let you fully appreciate quality of this machine. We recommend you to read it in each part before first time use. - Page 4 This manual forms an integral part of the vacuum cleaner and must accompany the machine during the life cycle. In case of loss or damage a replacement copy must be asked for to DEPURECO S.r.l. Technical information contained in this manual are DEPURECO property and are to be considered reserved.
-
Page 5: Main Parts Identification
Optionals A wide range of optional accessories is available from DEPURECO on basis of the application of your vacuum cleaner. Manufacturer identification data DEPURECO INDUSTRIAL VACUUMS S.r.l. Corso Europa, 609 - 10088 Volpiano (TO) - ITALY tel. -
Page 6: Identification Plate
- non-hazardous - dust sucking To clean hazardous dust ATEX Z 22, please, ask for the DEPURECO B1 version (BULL TRE only). If equipped with a special filter and a float, the vacuum cleaner may be used to clean non-flammable and non-corrosive liquids. -
Page 7: Noise Level
Noise level Noise tests conducted on these specific vacuum cleaner models reveal a sound pressure level of BULL UNO 70 dB(A) BULL TRE 76 dB(A) Warning! Workers exposed to sound pressure levels higher than 85 dB(A) must be protected by appropriate individual protection device as e.g. acoustic individual protection device type-approved. -
Page 8: Technical Data
Technical data Feature Unit BULL UNO BULL TRE BULL 3/S BULL 3/T lt/Gal lt/Gal lt/Gal lt/Gal lt/Gal lt/Gal lt/Gal lt/Gal 65/18 100/27 65/18 100/27 65/18 100/27 65/18 100/27 Weight* Kg/Lb 71/56 74/163 95/209 98/216 71/156 74/163 71/156** 74/163** Overall dimension* 80x65x160 80x65x160 80x65x170... -
Page 9: Guarantee
Guarantee DEPURECO guarantees this vacuum cleaner model for a period of 12 months from the date of purchase as indicated on the receipt for fiscal purposes emitted at the moment of product delivery by the retailer. Guarantee does not apply if the vacuum cleaner is repaired by unauthorized persons or if it is used with tools or accessories or components not supplied or not authorized from DEPURECO or if the serial number is found to have been removed or altered (during guarantee period). -
Page 10: Safety Section
An adequate training is an essential requisite (learn to recognize it). DEPURECO may in no way be hold responsible for accidents or damages as a result of vacuum cleaner use by not adequately trained personnel, incorrect use, or failure to comply, even partially, the safety norms and laws and adjustment procedures outlined in this manual. -
Page 11: Safety Measures
Safety measures Warning! The forward information are very important to fully prevent any risk operating with vacuum cleaner. Therefore (information) must be integrated by worker’s ability and common sense as well as indispensable ingredients for accident prevention. Each section lists further safety measures specific for the various functions. CAUTION ! •... - Page 12 • The present manual must always be nearby, so it may be consulted to check correct cycle use anytime there are some doubts. If it gets lost or damaged, a substitute copy must be requested to DEPURECO. Warning! This vacuum cleaner could contain dust that may be hazardous to your health.
-
Page 13: Safety Plates And Symbols
Clean them using a cloth, water and soap. Do not use solvents, naphtha or gasoline. Replace damaged plates, requesting them to DEPURECO. If a plate is located on a part that has to be replaced, ensure that a new plate is attached to the new part. - Page 14 Caution! Carefully read operation and maintenance manual before using or repairing vacuum cleaner. Caution! Carefully read the instructions on packaging before removing and unpacking the vacuum cleaner.
-
Page 15: Residual Risks
Warning! It is absolutely forbidden to remove the safety plates present on board of the vacuum cleaner and/or the components and the packaging. DEPURECO declines all responsibility for vacuum cleaner safety in the event this prohibition is unheeded. Applied Directives... -
Page 16: Handling, Unpacking And Installation Section
HANDLING, UNPACKING AND INSTALLATION SECTION Handling Caution! Instructions for correct transporting and unpacking of the vacuum cleaner are also displayed on the packaging. These instructions also explain the operations to be carried out in the event that the vacuum cleaner needs to be re-packed for, or unpacked following a subsequent move. -
Page 17: Unpacking
Unpacking - Unscrew screws of “L” fastening brackets and put off brackets. CAUTION: after putting off bracket, the screw you see in figure must be re-screwed completely to the vacuum cleaner. - Page 18 Caution! Cardboard packaging is a recyclable material and, in order to avoid environmental impacts, DEPURECO suggests you to bring it to separate collection. Caution! Save pallet and fastening brackets. In case of eventual future transport, vacuum cleaner must be anchored to the pallet...
-
Page 19: Installation
For more information, please contact Customer Service Dept. of your Dealer (or DEPURECO). - Lift knob (A) and insert the flexible tube with end-piece into the suction mouthpiece by releasing the knob. - Page 20 Connect to the fast air connection showed in picture. The pressure requirement must be max 6 bar. For correct working operation, the air supplied into the vacuum cleaner, must be dehumidified. need more information, please contact Customer Service Dept. of your Dealer DEPURECO directly).
-
Page 21: Operation Section
OPERATION SECTION Controls description Warning! Authorized personnel only that have read the present maintenance and operation manual may use this vacuum cleaner. Appliance user and maintenance technician that carry on authorized operations on the vacuum cleaner, must receive adequate training and information, as stated by current norms and requirements about work... -
Page 22: Work Cycle
BULL TRE 1 = Vacuum Gauge: signals that extracted filter is clogged 2 = Start / Stop Switch ON-OFF Work cycle Ensure that supply cord is intact and in a perfect condition. Warning! Before inserting the plug check that the electrical supply line voltage corresponds to the value indicated on the nameplate label of the vacuum cleaner. - Page 23 On BULL UNO Press the switch (2) and start vacuuming. To increase vacuuming power the second motor can be activated by pressing switch (3) and third motor by pressing switch (4). To turn off the vacuum cleaner press the previously activated switches. On BULL TRE model Turn the switch (1) on “I”...
- Page 24 In this case, to clean the filter, operate as follows: On BULL UNO - switch off the machine - push down the lever that locks the knob located on the top of the cover. - pull the knob up and down vigorously to shake out the internal filter. - lock again the knob, lift the appropriate lever and continue vacuuming.
-
Page 25: Emptying The Waste Container
On BULL TRE model Shake out the filter by moving vigorously - right-left direction - the lever you see in the picture Warning! If the vacuum cleaner does not work properly, after filter cleaning, it is possible that the filter is completely clogged and needs to be replaced. Emptying the waste container Warning! During this operation, appropriate and expected individual protection devices, as e.g. - Page 26 remove the container from vacuum cleaner, by means of the handle empty the container into another container approved for waste disposal under the laws of the country in which the vacuum cleaner is used...
- Page 27 Generally for the emptying operation and for making it in safety conditions for personnel, DEPURECO suggests the use of a nylon bag into the waste container (see Accessories Catalogue when expected). When the bag is full – up to about 3 cm under rim – to empty the...
-
Page 28: Inserting And Locking The Waste Container
Inserting and locking the waste container Insert the container under the vacuum cleaner lower completely the container locking lever using both hands. Pins (A), on both sides, must be aligned with grooves (B). Warning! Crushing hazard to the upper limbs! Never put hands between the waste container and the vacuum cleaner during the locking phase. -
Page 29: Maintenance Section
MAINTENANCE SECTION Warning! Vacuum cleaner extraordinary maintenance must be performed exclusively by specialized technician acknowledged by DEPURECO dealer. Informative notes This section contains the description of control operations and ordinary maintenance indispensable for granting continue performance of the vacuum cleaner. -
Page 30: General Safety Rules
General safety norms Warning! All interventions descripted must be performed with the power supply plug removed from the socket (and compressed air taken off). Before starting any maintenance or cleaning intervention personnel must wear appropriate individual protective devices (e.g. protective clothing, glasses, glovers, mask, etc.) adequate to the type of work to be performed. -
Page 31: Filter Replacement
Before each work shift - Check that the supply cable and the plug are not damaged. Whether damaged, replace immediately, using a cable of the same model (information from DEPURECO) – this intervention must be performed exclusively by an electrical maintenance employee. - Page 32 8. pull out the filter (E) and place all the components on a work bench. On BULL TRE model 1. turn off the machine 2. unscrew and take off and remove the silencer (F) 3. lift up the cover (G) and place it on a work bench, being careful not to damage the power cable.
- Page 33 Warning! This operation requires two people. 4. lift up the filter (H) and unscrew the two knobs (I) 5. remove the filter.
- Page 34 - on BULL 3 model screw the silencer (F) 7. connect the flexible tube 8. connect compressed air to fast air connection – see paragraph 3.3 9. connect power supply 10. turn on the vacuum cleaner, checking immediately the regular functioning. USE EXCLUSIVELY ORIGINAL DEPURECO FILTERS...
- Page 35 - Fit the new filter and secure everything with the nut (A) previously removed. USE EXCLUSIVELY ORIGINAL DEPURECO FILTERS type HEPA...
- Page 36 5.3.2 Complete “SP” kit with cartridge and cycle programmer Available for BULL UNO To replace the absolute filter, turn the top cover upside down and unscrew the nut filter secure everything with the nut (A) previously removed. Warning! Wear the appropriate individual protective devices (e.g. protective clothing, glasses, glovers, mask, etc.) adequate to this type of work.
-
Page 37: Troubleshooting
- Reset the circuit breaker BULL TRE - Circuit breaker triggered (BULL TRE) (BULL TRE) - Contact DEPURECO technical assistance - Shake out the filter. - Clogged filter If this is not enough, fit a new filter. The gauge shows incorrect... -
Page 38: Life Cycle End
Lyfe cycle end In the event of lyfe cycle end, to avoid damages to environment, each component of the vacuum cleaner, must be disposed of in a responsible way, in adequate dump in according to current laws - in Italy D.Lgs. 152/2006. - Page 39 MAINTENANCE INTERVENTION CHART INTERVENTION 1 Date Technical Assistance Type of intervention Signature INTERVENTION 2 Date Technical Assistance Type of intervention Signature...
- Page 40 MAINTENANCE INTERVENTION CHART INTERVENTION 3 Date Technical Assistance Type of intervention Signature Date INTERVENTION 4 Technical Assistance Type of intervention...
