The freeze flag is set when a freeze event occurs. If 0 is written to Freeze Flag (mm.104) the freeze flag is cleared.
Freeze Input State
mm.113
Minimum
0
Decimal places
0
Type
1 Bit Volatile
This parameter shows the state of the freeze signal from the drive.
Freeze Sensor Delay
mm.114
Minimum
0.0
Decimal places
1
Type
16 Bit User Save
Any delay in the sensor used to trigger a freeze event will cause the freeze position to advance (giving a larger freeze position) in the forward direction
or retard (giving a smaller freeze position) in the reverse direction compared to the actual physical position. This effect becomes worse as the speed
is increased. The error is given by:
Freeze Error = (Speed (rpm) / 60) x 2
Normalised Position Bits is the number of bits representing one turn given by:
Normalised Position Bits = 32 – Normalisation Turns (mm.057)
The time delay due to the drive and option module electronics is less than 500 ns for either the digital I/O or the marker inputs. However, external
sensors can significantly increase the delay. Freeze Sensor Delay (mm.114) can be used to cancel the effect of the sensor delay and prevent
unwanted advancing or retarding to the freeze position at higher speeds.
