mm.001 Module ID
Minimum 0
Decimal places 0
Type 16 Bit Volatile
This parameter displays the ID number for the option module. For the SI-Encoder V2 module this is 105.
mm.002 Firmware Version
Minimum 0
Decimal places 0
Type 32 Bit Volatile
mm.022 Active Alarm
Minimum 0
Decimal places 0
Type 8 Bit Volatile
Value Text
0 None
1 Low Battery
This parameter shows the currently active alarm. If this option module is not indicating an alarm this parameter shows None (0).
mm.024 Module Temperature
Minimum -50
Decimal places 0
Type 16 Bit Volatile
Displays the temperature measured on the module printed circuit board. The module will initiate an Overheated (106) trip if the measured
temperature exceeds 90 °C.
mm.027 Speed Feedback
Minimum -50000.0
Decimal places 0
Type 32 Bit Volatile
Provided the set-up parameters for the encoder connected to this module are correct this parameter shows the speed derived from the feedback in
rpm. The value shown is measured over a 16 ms sliding window period.
