The following addresses are allowed in each type of encoder:
SMART-ABS
Page Address
0 to 5 0x00 to 0x7E
7 0x04
7 0x05
Sankyo
Page Address
0 0x00 to 0x6F
0 0x7E
0 0x7F
mm.068 User Comms Transmit Register
mm.069 User Comms Receive Register
Minimum 0
Decimal places 0
Type 16 Bit Volatile
Device Type (mm.038): AB
These parameters have no effect.
Device Type (mm.038): SMART-ABS, Sankyo
See User Comms Enable (mm.067).
mm.070 Position Feeedback Signals
Minimum 000000000 (0)
Decimal places 0
Type 16 Bit Volatile
This parameter shows the state of the signals from the position feedback device as given in the table below. This parameter is intended as a
debugging aid.
Device Type (mm.038): AB
Position Feedback Signals (mm.070) Bits
0
1
Device Type (mm.038): SMART-ABS, Sankyo
The only signal connection between the drive and the encoder is the communications link which changes too fast to be viewed in a parameter. To
assist with debugging this parameter shows the error status byte from the encoder. The tables below show the meaning of each bit.
SMART-ABS
Bit Meaning
0 Over-speed
1 Low resolution
2 Counting error
3 Counter overflow
4 Encoder temperature
5 Multi-turn error
6 Low battery
Battery alarm. The battery is below the allowed threshold while the encoder
7
is powered up.
Bits 0 to 7 are being updated. If this bit is zero then Bits 0 to 7 show the
8
value the last time the data was read from the encoder.
SI-Encoder V2 User Guide
Mechanical Installation
Function
Read/write memory
Over temperature threshold
Encoder temperature
Function
Read/write memory
Over temperature threshold
Low voltage threshold
Maximum
Units
Display format
Maximum
Units
Display format
Electrical Installation Getting Started
Read/write
Read/write
Read/write
Read only
Read/write
Read/write
Read/write
Read/write
65535 Default
Update rate
Standard Coding
111111111 (511) Default
Update rate
Binary Coding
Signals
A
B
Trip
number
107
108
109
110
111
112
113
Parameters
0
Background read/write
RW, NC, PT, BU
Background write
RO, ND, NC, PT
Encoder Initialisation Mode (mm.075) value
required to reset encoder trip indication
1 or 2
1 or 2
1 or 2
1 or 2
2
2
