Press
Pull

Figure 33: Cradle Front and Rear Separation

5. Remove the cradle front by carefully pulling it out from the pole.
Note:
Care must be taken not to damage the cables/connectors during cradle front removal.

Figure 34: Cradle Front Removal

DPU-00084
Page 35 of 39
Revision 2.3
