Vix Assure Adept Validator Installation Manual page 3

Document History
REVISION
REVISION
DATE
0.1 14 Jun 2021
0.2 27 July 2021
0.3 13 Dec 2021
1.0 15 Dec 2021
1.1 03 Mar 2022
1.2 15 Mar 2022
2.0 15 Mar 2022
2.1 04 Apr 2022
2.2 23 Jun 2022
2.3 23 Jun 2022
DPU-00084
Revision 2.3
DESCRIPTION
Initial Draft.
Updated with review comments.
Updated document template;
Restructured document;
Added more instructions.
Formal Release
Added info on accessories (re)placement;
Added 1-wire assembly;
Added wiring and termination info.
Changed rear connector pinouts;
Addressed review comments:
Mainly on the wiring diagram and ferrite/cable
specifications;
Added example on the current rating per conductor as
a function of the number of conductors;
Changed Adept to Adept Validator and other minor
wording adjustments.
Released for use.
Added installation for 4G/GPS;
Added battery section;
Added ferrites should be installed before cradle
mounting;
Changed pole cut-out;
Added cradle part number and information on the
cradle cover and extra parts to suit poles of different
diameter.
Changed the way how the cradle kit is delivered and
added instructions on how to disassemble it to be
ready for installation;
Added 1-wire module pinouts.
Added FCC & ISED compliance statement
Page 3 of 39
AUTHOR
Atul Sharma
Atul Sharma
Carrie Huang
Atul Sharma
Carrie Huang
Carrie Huang
Carrie Huang
Carrie Huang
Carrie Huang
Steven Yeh
