8. Wrap the cover around the cradle sub-assembly from the back and clip it in place.
9. Feed the cables through the protective rubber boot to provide environmental protection. Ensure there is
sufficient slack for the Adept Validator connection and mounting.
Note:
For an Adept Validator model with GPS, the GPS cable is NOT required to be fed through the
rubber boot, and it should go through a different opening as indicated.
DPU-00084
Revision 2.3
Figure 21: Seals Position on External Cover
Figure 22: Adept Validator Cradle Mount Cover
Page 29 of 39
