 If the water flow rate is too low (less than 5 m³/h), or if the filtration is stopped, the "reg" indicator light
will flash and the heater will stop heating,
 When the pool has reached the desired temperature, the "reg" indicator light goes out, the heater will
stop heating.
3.3 Checks to be carried out after operating for a few moments
Check that the heater stops heating when:
 the setpoint temperature is decreased or when the control is shut off,
 filtration is switched off.
3.4 Winter storage
Winter storage is essential due to the risk of body of the heater freezing and breaking. This situation is
not covered by the warranty.
 Turn off control unit power,
 Shut off water circulation,
 Drain the heater :
- close valves 2 and 3 (see §2.2), if installed,
- unscrew the fittings to drain the heater,
- when the heater is empty, lightly retighten the fittings, without creating a seal.
4. Maintenance
4.1 Maintenance instructions
It is recommended that the device be general serviced on a yearly basis to ensure proper operation,
maintain performance levels and prevent some potential failures.
This is the responsibility of the user and must be performed by a qualified technician.
 Check the electrical components,
 Check the ground connection,
 Check that the electric cable connections are properly tightened and that the electric box is clean
4.2 Recycling
This symbol means that your device must not be thrown in the bin. The device must be collected by a
selective system in view of re‐use, recycling or similar. Any substances it may contain which are
potentially dangerous to the environment shall be eliminated or neutralised.
Request information on recycling procedures from your retailer.
5. Resolution of problem
5.1 Malfunctions of the device
Dysfunction
The display does not
work
The appliance displays
a flashing "E0"
The pool water is
hotter than requested
The "reg" light is on
but the appliance
does not heat
H03609‐00.B1.EN – 2012/01
Causes
Power is not supplied to the
appliance
The control sensor is out of service
or disconnected
The regulator is not operating
correctly
the positive safety overheating
thermostat (TS) has been tripped
the appliance has not been installed
in compliance with instructions
The regulator fuse is blown (for replacement,
see §5.2)
Appliance power off and locked out, reconnect
or standard replacement of the sensor (the "E0"
fault is automatically cleared)
check that the power contactor is not damaged
reset it by removing the small cap to the side of
the appliance and by pressing on its central cap
contact an approved technician
solution
